Low pressure CIR90 SPM90 90mm tungsten carbide drill rock DTH hammer drill bit for rock price
Low pressure CIR90 SPM90 90mm tungsten carbide drill rock DTH hammer drill bit for rock price
Low pressure CIR90 SPM90 90mm tungsten carbide drill rock DTH hammer drill bit for rock price
Low pressure CIR90 SPM90 90mm tungsten carbide drill rock DTH hammer drill bit for rock price
Low pressure CIR90 SPM90 90mm tungsten carbide drill rock DTH hammer drill bit for rock price
Low pressure CIR90 SPM90 90mm tungsten carbide drill rock DTH hammer drill bit for rock price
Low pressure CIR90 SPM90 90mm tungsten carbide drill rock DTH hammer drill bit for rock price

Low pressure CIR90 SPM90 90mm tungsten carbide drill rock DTH hammer drill bit for rock price

Share on (60816285066):


Price:RUB 4,541.50

Quantity:


Product Overview

Description

Product Description

Low pressure CIR90 SPM90 90mm tungsten carbide drill rock DTH hammer drill bit for rock price

SPM CIR90 Low Pressure DTH Air Drill Hammer bit is very popular in international ore mining drilling field.

It is widely used in international ore mining drilling field. Drill-the-hold hammer.
SPM CIR90 DTH Drill Hammer drill holes from 90mm to 130mm.
Matched drilling bits:SPM CIR90-90,SPM CIR90-100,SPM CIR90-110,SPM CIR90-120,SPM CIR90-125,SPM CIR90-130.
We also supply other 3",5",6",8",10",12" High Pressure DTH Air Drill Hammers and various matched drill bits,
We offer SPM low and high air pressure DTH hammer size from 3" to 12"(Φ71mm-Φ275mm), SPM DTH hammers perform good in drilling well of diameter from 65mm to 600mm, especially excellent in deep hole well drilling works.
Different designing makes SPM DTH drill hammers are suitable for various well drilling conditions.

Low air pressure CIR90 DTH drill bit
Suitable Bit
Bit Diameter
Number* Button Diameter (Outer)
Number* Button Diameter(Inner)(Front)
Flushing holes
Bit shank
Weight
(kg)
inch
mm
SPM90B
3 1⁄2
90
6*Φ14
4*Φ12
3
CIR90
3.8
SPM90T1
3 1⁄2
90
6*Φ14
3*Φ12 1*Φ12
2
CIR90
3.6
SPM90T2
3 1⁄2
90
6*Φ14
2*Φ12 2*Φ12
2
CIR90
3.8
SPM90T3
3 1⁄2
90
6*Φ14
2*Φ12 2*Φ12
3
CIR90
3.8
SPM90T5
3 1⁄2
90
5*Φ14
2*Φ12 2*Φ12
3
CIR90
3.6
SPM90-100
4
100
6*Φ14
2*Φ12 3*Φ12
3
CIR90
4
SPM90-110
43⁄8
110
6*Φ14
2*Φ12 3*Φ12
3
CIR90
4.5
SPM90-120
4 3⁄4
120
6*Φ14
2*Φ12 3*Φ12
3
CIR90
5.5
SPM90-125
47⁄8
125
6*Φ14
3*Φ12 3*Φ12
3
CIR90
6
SPM90-130
51⁄8
130
6*Φ14
3*Φ12 4*Φ12
3
CIR90
6.8

Main Features

1. portable
2. fast drilling speed
3. stable performance
4. saving air consumption
5. longer service life

Certifications
Our Company



Xuanhua Superman DTH Machinery Co., Ltd is a national high-tech enterprise, located in Xuanhua, 150km northwest of Beijing, a renowned industrial zone that has a title of "NO. 1 Prefecture West of Beijing".


Covering a wide range of mining, excavating and constructing, the products of our company can be equipped in mines, petroleum, hydropower, transportation, forestry, geothermal drilling, well, photovoltaic and new energy industry, etc. Taking the world's leading position in down-the-hole drilling technology especially, the company has a business connection with dozens of countries.

Our Service


  We guarantee that we supply customers with leading drilling products by our superior service and effective scheme. Meanwhile, we have been pursuing the goal that we shall do utmost to improve the service life of product, reduce the maintenance cost, and provide a perfect solution. Sincerely welcome friends from home and abroad, we will provide you product with the highest quality, and show our greatest sincerity for establishing the business relationship!

Packing & Delivery
Packaging
Packing
Wooden case or cardboard box with foam
Weight
3.8-6.8kg



Deliver
Details


1. Standard exporting package, wooden case or as your choice.

2. Shipping: By sea / By air / By express
