500kg 1100mm 1300mm Semi Electric Portable self loading pallet lift Self Lift Stacker
- Category: >>>
- Supplier: Wuxi Welift Machinery Co. Ltd.
Share on (60817349179):
Product Overview
Description
SS-05B SEMI ELECTRIC SELF LIFT STACKER
| Model | SS-05B | SS05B | |
| Capacity | Q(Kg) | 500 | 500 |
| Load center | C(mm) | 400 | 400 |
| Type of lifting | Electric | Electric | |
| Operating type | Walkie | Walkie | |
| Material | PU/Nylon | PU/Nylon | |
| Wheel base | y(mm) | 860 | 860 |
| Front wheel base | b11(mm) | 380 | 380 |
| Back wheel base | b10(mm) | 670 | 670 |
| Quantity Steering/Bearing/Balance | 2002-2-6 | 2002-2-6 | |
| Bearing wheel size | mm | Φ70×60 | Φ70×60 |
| Steering wheel size | mm | Φ100×50 | Φ100×50 |
| Balance wheel size | mm | Φ40×26 | Φ40×26 |
| Training wheel size | mm | Φ30×26 | Φ30×26 |
| Min.fork height | mm | 90 | 90 |
| Max.fork height | h3(mm) | 1100 | 1300 |
| Fork outside width | mm | 535 | 535 |
| Fork inside width | mm | 225 | 225 |
| Fork length | l2(mm) | 1150 | 1150 |
| Single fork size | e/s(mm) | 155/60 | 155/60 |
| Overall length | L1(mm) | 1600 | 1600 |
| Overall width | b1(mm) | 790 | 790 |
| Overall height | h1(mm) | 1400 | 1600 |
| Whole height(after tape file shelf) | h4(mm) | 2700 | 2900 |
| Min.turning radius | Wa(mm) | 1100 | 1120 |
| Lifting speed(laden/unladen) | mm/s | 80/110 | 80/110 |
| Lowering speed(laden/unladen) | mm/s | 80/80 | 80/80 |
| Lift motor | Kw | 12V0.8 | 12V0.8 |
| Battery capacity | V/Ah | 12/33 | 12/33 |
| Battery weight | Kg | 10 | 10 |
| Net weight | Kg | 197 | 219 |
For more operation video and more details please visit our Youtube Channel:
https://www.youtube.com/watch?v=itccorCg7LY
