Sj Series Single Screw Plastic Extruder Manufacturer plastic extruder machine
- Category: >>>
- Supplier: Zhangjiagang Xingda Machinery Co. Ltd.
Share on (60818537208):
Product Overview
Description
Product Description
pe pp pipe extruder
SJ series single screw extruder
| Model | Screw diameter (mm) |
Rotational speed (rpm) |
Motor power (kw) | Motor type | Output (kg/h) | Center height (mm) |
| SJ-25/25 | 25 | 25 | 1.5 | AC | 3 | 1000 |
| SJ-30/25 | 30 | 50 | 2.2 | AC | 5 | 1000 |
| SJ-65/30 | 65 | 20-120 | 45 | AC | 150 | 1000 |
| SJ-65/33 | 65 | 20-120 | 55 | AC | 200 | 1000 |
| SJ-75/33 | 75 | 12-120 | 75/90/110 | AC | 350 | 1000 |
| SJ-90/33 | 90 | 12-120 | 160 | AC | 450 | 1100 |
| SJ-120/33 | 120 | 10-80 | 250/315 | AC | 850 | 1200 |
| SJ-150/33 | 150 | 7.5-75 | 315 | AC | 1200 | 1300 |
Noting:
Please feel free to contact us for more information. Additionally, it is worth noting that, it will be more advantageous if you told the diameter and more details of the pipes you are going to produce when sending your messages.
FAQ
1). What kinds of plastic machinery do you need ? Or what material do you want to process?
2). What capacity do you want? (kg/h )
3). What is the max and min size of the finish products .For example, the diameter of pipe(inch or mm); thickness of pipe wall(mm)?
4) What is the electrical device you need ? Siemens, Omron or domestic ?
5) When do you want the machine? (Times for delivery)
6) Other requirements about the machine you want.
