high temperature machinable ceramic tube rod custom made supplier

Share on:

Price:$0.10 - $3.00
Price in USD:Details


Product Overview


high temperature machinable ceramic tube rod custom made supplier

Reputation depends on quality, quality comes from Hard!

Product Description

Macor mica machinable Ceramics:

Microcrystalline glass ceramics, also known as machinable ceramics, are mica glass-ceramics with synthetic mica as the main crystalline phase, and are ceramic materials that can be machined. Microcrystalline glass ceramics have excellent processing properties, vacuum properties, electrical insulation properties, and high temperature and chemical resistance. Glass-ceramics with high mechanical strength, glass-ceramics, machinable glass-ceramics and bioactive glass-ceramics

Macor ceramics have excellent processing properties, vacuum properties, electrical insulation properties, and high temperature and chemical resistance. Glass-ceramics with high mechanical strength of glass-ceramics, machinable glass-ceramics and bioactive glass-ceramics

1. High intensity and light weight
Glass-ceramics are harder than natural stone and are not easily damaged. The thickness of the material can be matched with the construction method, which is in line with the light and sturdy mainstream of modern buildings.

2, rich and varied colors
Glass-ceramics are made by the accumulation method. There is no natural stone texture (which breaks from here). The accumulation method is a method that can produce rich color tones, with a white color as the basic color and a rich color system, and white The three colors of rice and gray are most often used.

3. Excellent weather resistance and durability
The acid-resistant and alkali-resistant glass-ceramics are superior to granite and marble, and are inherently inorganic materials. Even when exposed to wind and rain and polluted air, they will not cause deterioration, fading, and inferior strength.

4. Electrical Properties

Microcrystalline glass ceramics is an excellent high-temperature electrical insulating material that can be used in many electrical equipments. It has high electrical insulation strength.

5,corrosion resistant

because it is completely composed of inorganic materials, so there is no aging and no deformation, very stable to various organic solvents and good acid and alkali corrosion resistance.


High hardness, high strength, wear resistance, corrosion resistance, high temperacture (1600°), good thermal diffusivity, good insulativity, low cost etc.

 1.jpg3.jpg4.jpgmachinable cera2mic 2.jpgmachinable ceramic 2.jpgmachinable ceramic 3.jpg

Data Sheet↓


Machinable mica (Macor) Ceramic Properties
Item Unit Typical Values
Physical Properties
Color  White
Main Composition Mg3K[AlF2O(SiO3)3],SiO2
Apparent Porosity 0.07%
Water Absorption 0
Normal Temperature Outlet Rateml/S·cm28.8*10-9
Helium Transmission Rateml/S1*10-10
Mechanical Properties
Rockwell Hardness(45N)R45N40
Vickers Hardness (Load 500g)Gpa(Kg/mm2)11.5(1175)
 Flexural Strength (20°C)Mpa>108
 Compressive Strength (20°C)Mpa>508
 Modulus of Elasticity (25°C)Gpa65
Impact ToughnessKJ/m2>2.56
 Thermal Properties
Thermal Conductivity (25°C)W/m.K1.71
 Thermal Expansion Coefficient10-7/°C72
 Thermal Shock ResistanceT°C200
 Perennial Temperature°C800
 Electric Properties
 Dielectric Strength KV/mm>40
Volume Resistivity(25°C)Ω.cm1.08*1016
Volume Resistivity(200°C)Ω.cm1.5*1012
 Volume Resistivity(500°C)Ω.cm1.1*109
 Dielectric Loss 1-4*10-3
 Dielectric ConstantEr6-7


Application industry:

Machinery, electronic, limitary, aerospace etc.

Specific application: Machined equipment high temperature insulated parts, electronic equipment high temperature insulated parts.

Macor ceramics are particularly suitable for automotive, military, aerospace, precision instruments, medical equipment, electric vacuum devices, electron beam exposure machines, textile machinery, sensors, mass spectrometers and energy spectrometers. For some thin-walled coil bobbins, precision instrumented insulation brackets, and complex-shaped devices with high precision requirements, glass-ceramics are more suitable, and they can be processed into any shape.

Company Information

Shenzhen Hard Precision Ceramic CO.,Ltd founded in 2007, located in Shenzhen of China. We are a company that integrates development, design, moulding, sintering, production and sales of precision ceramic products. After 10 years of development, we have cooperated with more than 2000 customers and 60 universities; our factory covers an area of 2000 square meters, 50 employees, and annual production value of nearly 20 million. We have a higher visibility and better reputation in the same industry.


Compared with metals material, ceramic materials have excellent properties such as high hardness, high strength, high temperature(fire) resistance, wear resistance, corrosion resistance, acid and alkali resistance, oxidation resistance, insulation, nonmagnetic, good chemical stability and other excellent performance, so it is often used in the environment of the metal material is not up to. Advanced ceramics application prospect are very widely. It’s widely used in aerospace, aviation, military industry, nuclear power, machinery, textile, chemical, electronic, food, medical, etc. We provide alumina ceramic, zirconia ceramic, silicon nitride (Si3N4) ceramic, macor (mica glass ) ceramic, aluminum nitride (AIN) ceramic, silicon carbide (SiC) ceramic, boron nitride (BN) ceramic, quartz ceramic, mullite ceramic, cordierite ceramic etc.


Our products include ceramic rods, ceramic tubes, ceramic pipes, ceramic plates, ceramic sheets, ceramic blocks, ceramic nozzles, ceramic plungers, ceramic washers, ceramic spacers, ceramic substrates and precision parts for industrial. We have all-line high precision equipment from ceramic forming, sintering to precision machining. Hope for a wide range of sincere cooperation with customers at domestic and abroad.


Why Choose Us?

1.12 years of professional production industrial ceramics factory
2.High quality products with low price
3.High precision parts with lowest tolerance
4.Short time for production
5.Has a group of experienced, professional and efficient R&D team
6.Has a good reputation in China and abroad.
7.MOQ is not limited, small quantity is welcome.
8.Vigorous team and good after-sales service



Product Show

 mica glass ceramics.JPG

Factory Show

 Manufacture Process 1.jpgCeramic Factory.jpgCeramic Machines.jpgCeramic QC.jpgceramic sample.jpg




Our Team

 Company Show.jpg



Q: Are you trading company or manufacturer ?
A: We are factory.


Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-30 days if the goods are not in stock, it is according to quantity.


Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
