3 тонны на подметально уборочную дорожную машину грузовик с 4 щетка Тип

Product Overview

Description

3 ton road sweeper truck with 4 brusher type

Road sweeper truck, Road cleaning truck, which is used for road enviroment maintainess.

our company product two kind of road cleaning truck, side brusher with rear suction model, vaccum suction model, and the model that side brusher with water washing,and rear suction.

Currently our company produce this kind of trucks with its weight from 1 ton to 25 ton. exactly design could be according to customer requirement.

• 3 ton road sweeper truck with 4 brusher type, Introduction in detail


• road sweeper truck, sweeper truck, sweeper

Item		Unit		Description
Model				Dong Feng brand Water Spraying Truck
Dimension		mm		5995*1990*2590
Curb Weight		kg		5100
G.V.W		kg		7300
Wheel Base		mm		3300
F/R track base		mm		1506 / 1466
F/R Axle-load		Kg		1500 / 4000
		Type		Steel Spring
Approach/Departure angle		.		19 / 12
Traction system		Type		4*2 or 4*4
Max speed		Km/h		85
Tire Specification/Number		Model		7.00-16 / 6 +1 Spare Unit
Engine model		Model		YC4D95Z-T20
		Emission/Ps		4214 cc / 99 Ps,   70 Kw
		Horse Power		95
		Power		340 N.m-1400~1800r/min
		Type		Diesel, 4cylinder,Turbocharge,water cooling
		manufactuere		Guangxi Engine Power Co.,Ltd
Gear box		model		5F&1R,  Manual
Electronic		V		12
Cab		Person		3
		Type		Reversable, Manual
		Steering		Powering , LHD
		Installing		Mp3, Radio
		Air Conditioner		Hot Wind / Cold Wind
Remark:		Installing the water pump , side input or output port, Rear operation platform Option~ Installing beam alarm light, installing dot alarm light.rear LED alarm light.
Specification of Sweeper
Auxiliary Engine model		JX493ZQ3		Emission/kw			2771ml/55kw ,  75Hp
		4 cylinder, Tubocharged and Aftercooled.
Engine Manufacturer		JiangLing Engine Power Co.,Ltd
Stainless steel Dustbin		4.5 m3		Volume of Water Tank			1 m3
Max.cleaning width		3500mm		Max.cleaning Capacity			30000 m2/h
Max.Tipping Angle		45°		Max.Sunciton 0bject			<=100mm (2g/cm3)

• sweepers and vacuum truck, More Photos showing


• road sweeper truck, sweeper truck, sweeper

• More Photos showing about our sweeper trucks


• road sweeper truck, sweeper truck, sweeper
