Oem Single Row Ball Precision Slewing Bearing without Gear Replacement of KAYDON MTO 150T

Product Overview

Description

Introduction MT Series slewing ring bearings have a rectangular cross-section and range in size from 4 – 47 inches OD (100 – 1200 mm). They provide optimal economy and capacity for a given envelope dimension. Design Features The internal configuration consists of deep groove gothic arch raceways and maximum ball complement.



This results in a four-point contact design which provides exceptional moment, thrust, and radial load capacities. Integral face riding seals for the larger sizes and non-contact shields for the smaller assist in the exclusion of contaminants. These features make them an ideal choice for a wide range of applications from light to heavy duty. MT Series bearings are offered in non-geared (MTO) and externally geared(MTE) configurations. The gears are Fellows Stub Involute up to the MTE-324 size and Stub Involute for larger sizes, all manufactured to AGMA Class Q6 quality. Contact Kaydon for tooth backlash allowance. Part numbers ending in a “T” suffix have threaded mounting holes. Thread depths are a minimum of 1.5 times the nominal hole size diameter indicated.Part numbers ending in an "X" suffix provide additional load capacity. Availability MT Series bearings are generally available from stock, and mating pinions for the geared versions through MTE-705 are also generally available. Refer to page 70 for mating pinions.

Applications MT Series bearings have been used successfully in a wide range of applications from light to heavy duty.



In harbour crane and shipyard crane, slewing ring bearingserves as a joint between the upper structure and the undercarriage, providing a means of 360-degree rotation.



Xuzhou Wanda Slewing Bearing Co.,Ltd. is a slewing bearing manufacturer specializing in standard and non-standard slewing bearing.Over the years, we keep supplying high quality product & good service to customers of crane.

We have strict quality control system in our own factory,meanwhile, we have passed ISO9001:2008 Quality System Certification, certificates of Bureau Veritas and China Classification Society .



Besides, we have advanced production equipment and technology to meet high precision of slewing bearing. And we have professional engineers for slewing ring bearing selection.

I



If you have any question,please contact us!
