24V 30W Single Output SMPS Power Supply PCB Model
- Category: >>>
- Supplier: Guangzhou Kaihui Electronics Co. Ltd.
Share on (60819213944):
Product Overview
Description
24V 30W Single Output SMPS Power Supply PCB Model
Product Description
Features:
1,With wide application,they had been used in LED lighting,ACS,medical and beauty device,electrical power system,communication system,military industry and others.
2,Some models achieved GS,CE,CCC,ETL,ISO,ROHS certification now.
3,There are more than 1,000 kinds of models.
1,Wide rangeAC input voltage; | ||||||
2, short circuit, overload protection; | ||||||
3,Other output voltage also can be made,such as18V,21V,42V etc. | ||||||
parameter Item No. | KPSH30-5 | KPSH30-1 | KPSH30-24 | |||
OUTPUT
| DC Output Voltage | +5V | +12V | +24V | ||
Output Rated Current | 5A | 3A | 1.5A | |||
Output Current Range | 0- 5A | 0-3A | 0-1.5A | |||
Rated power | 25W | 36W | 36W | |||
Ripple | 100mVp-p | 100mVp-p | 100mVp-p | |||
ADJ.output range | 4.7~5.5V | 10.8~13.2V | 20.8~25..2V | |||
Output Accuracy | ±1% | ±1% | ±1% | |||
Line Regulation | ±0.5% | |||||
Load Regulation | ±0.5% | |||||
Set up,Rise,Hold up time | 500ms,50ms,20ms | |||||
INPUT
| Input Voltage range | 170-264VAC | ||||
Input current | 0.3A@ 220VAC | |||||
Input frequency | 47~63Hz | |||||
Efficiency | 84% @ 220VAC | 84% @ 220VAC | 84% @ 220VAC | |||
| Inrush current | Cold start 15A/115V,30A/230V | |||||
| Leakage Current | <0.3mA@240V AC | |||||
Over Temp.protection | Over load protection | 110~200%,Hiccup protection, automatic recovery | ||||
| Over voltage | ------ | |||||
| Over Temp. | ------ | |||||
ENVIRONMENT
| Working Temp.,Humidity | -10~50℃,10~90% RH,No condensation | ||||
Storage Temp.,Humidity | -20~85℃,10~95% RH. | |||||
Temp.Coefficeent | ±0.03%/℃(0~50℃) | |||||
Vibration | 110~500Hz, 2G 10min./1cycle, PERIOD FOR 60min. EACH AXES | |||||
SAFETY&EMC
| Safety standards | GB4943 | ||||
Pressure | I/P-O/P :1.5KV DC 1min. | |||||
Insulation resistance | I/P-O/P, I/P-FG, O/P-FG:500VDC / 100M Ohms | |||||
EMC standards | EN55022 CLASS B,GB9254 CLASSB | |||||
OTHER
| Demension | 92*46*25mm | ||||
Weight | 0.1Kg | |||||
| Note: | 1. All parameters 220VAC input, rated load, ambient temperature 25 ℃, measured under conditions of 70% humidity; 2.Accuracy: includes set up tolerance, line regulation, load regulation and so on; 3. Ripple Test: 30cm long strands connect the power supply and the load, the load side and 0.1u and 47u capacitor to 20MHz oscilloscope measured at the load end; 4. Line regulation: at rated load conditions, the input voltage changes from low to high measured; 5. Load regulation: the measured output from 0% to 100% load change load measured. |
Related Products
Packaging & Shipping
Payment&Shipping Payment Shipping |
FAQ
Q1. Can I have a sample order for power supply?
A1: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: Do you accept OEM/ODM for the switching power supply ?
A2: Yes. we do.
Q3:How about the quality?
A3:We have the better professional and experienced engineers team and strict QA and QC system.Repair rate under 0.1%~0.2%
Q4:What is PFC?
A4:PFC stands for Power Factor Correction. The purpose of PFC is to improve the ratio of apparent power and real power. The power factor is only 0.5~0.7 in non-PFC models. In PFC models, the power factor can reach above 0.9. The calculation formulas are as below:
Apparent Power=Input Voltage x Input Current (VA)
Real Power= Input Voltage x Input Current x Power Factor (W)
