ip65 waterproof 12v/24vdc micro motor linear actuator for solar tracking system
- Category: >>>
- Supplier: Zhejiang Nakin Intelligent Technology Co. Ltd.
Share on (60819749171):
Product Overview
Description
ip65 waterproof 12v/24vdc micro motor linear actuator for solar panel system
Product Parameters
- Linear Actuator with strong and quiet design.
- Max3000N load
- Used in a wide range of industries.
| Input Voltage | 12/24/36/48VDC |
| Max Load | 1000N |
| Max Speed at Full Load | 3mm/s |
| Stroke | 100~400mm(or customize stroke) |
| Inner Tube | Aluminium alloy |
| Color | Black or Grey |
| Limit Switch | Built-in |
| Overload Protection | integrated in appropriate Control-Box |
| Duty Cycle | 20% |
| IP Grade | IP54/IP65 |
| Operating Temperature | -26°C ~ +65°C |
| Standard | CE/UL |
Product Pictures
Packing & Shipment
| Packaging | Export standard carton or according to your request |
| Deliver time | Sample: 5-10 working days(Usually) |
| Bulk Order: 20-25 working days based on your quantity |
Product Range
- Linear Actuators
- Industrial Actuator
- Home Furniture Actuator
- Medical & Careline Actuator
- Deskline Actuator
- Lifting Columns
- Dual Actuators
- Control Boxes
- Controls
- Accessories
linear actuator
Note :
*All linear actuators are customized according to customer's requirement .
*please tell us the following information when you send inquiry , so that we can suggest you the suitable linear actuator .
1. load force
2. stroke length
3. input voltage
4. full load speed
5. mounting length
6. application
