12 В 250 В электромагнитное магнитное фиксирующее реле, твердотельное реле ma ger

Item

Value

Perating Speed

0.1mm~1m/s(Related with actuator forms)

Operating Frequency

Mechanical 60 cycles/min;Electrical 30 cycles/min

Insulation Resistance

100 MΩ (500VDC)

Contact resistance

<=30mΩ(Initial value)

Test Voltage

Between terminals of the same polarirty

AC1000V,50/60Hz,1min

Between current-carrying metal

And ground(case),and between

Each terminal and non-carrying

metal parts

AC2000V,50/60Hz,1min

Vibration resistance

10-55Hz,1.5mm Double amplitude

Shork Resistance

Destruction : OF>0.5N:1000m/s ²(approx.100G)max

           OF<=0.5N:500m/s ²(approx.50G)max

Malfunction: OF>0.5N:300m/s ²(approx.30G)max

           OF<=0.5N:200m/s ²(approx.20G)max

Life Expectancy

Mechnical>=5000000 cycles

Electrical>=50000 cycles

Degree of protection

IEC IP40

Degree of protection against electric shock

Class I

PTI(Tracking Resistance)

175

Ambient air temperature

125°C 60%RH below(No ice and dew)

Ambient air humidity

85% Rhbelow(about +5~+35°C)

Weight

Approx.5.95g(No lever)
