  • ADTECH high speed smt pick and place robot price palletizzing machine automatic palletizer
ADTECH high speed smt pick and place robot price palletizzing machine automatic palletizer
ADTECH high speed smt pick and place robot price palletizzing machine automatic palletizer
ADTECH high speed smt pick and place robot price palletizzing machine automatic palletizer
ADTECH high speed smt pick and place robot price palletizzing machine automatic palletizer
ADTECH high speed smt pick and place robot price palletizzing machine automatic palletizer
ADTECH high speed smt pick and place robot price palletizzing machine automatic palletizer
ADTECH high speed smt pick and place robot price palletizzing machine automatic palletizer

ADTECH high speed smt pick and place robot price palletizzing machine automatic palletizer

Share on (60820246719):


Price:$1,500.00 - $2,000.00

Quantity:


Product Overview

Description


Application
Click for Videos

Sorting

Drawing

Burring

Scanning

Labeling

Assembling

Product Description
\t
Model
\t
ADT-AR4215
\t
Type
\t
Scara robot
\t
Number of axis
\t
4 -axes
\t
Arm length
\t
400mm
\t



Axis specification
\t
X-axis
\t
arm's length
\t
200mm
\t
Rotating range
\t
±127°
\t
Y-axis
\t
arm's length
\t
200mm
\t
Rotating range
\t
±142°
\t
Z-axis
\t
travel
\t
150mm
\t
A-axis
\t
rotation range
\t
± 360 °
\t



Max. speed
\t
X-axis
\t
600 °/s
\t
Y-axis
\t
600 °/s
\t
X,Y axis synthesis
\t
6.3 m/s
\t
Z
\t
1.3 m/s
\t
R
\t
1667 °/s
\t
Standard cycle period
\t
0.4s
\t


Repeat positioning accuracy
\t
X,Yaxis
\t
0.01mm
\t
Z
\t
±0.01mm
\t
R
\t
±0.005°
\t
Max load / Rated load
\t
2/5kgs
\t
R-axis allowed load inertia
\t
Max inertia
\t
0.005 kg.m^2
\t
Rated inertia
\t
0.035kg.m^2
\t
User signal line
\t
0.2sqx16 line, 6 channel input and 8 channel output
\t
User pipe
\t
φ 6*2 root
\t
Limit protection
\t
1, software limited 2, mechanical limit (x, y, z axes)
\t
Weight
\t
13.3Kg
Hot Selling
Company Profile

ADTECH / STEP (Stock Code:002527)

ADTECH (SHENZHEN) TECHNOLOGY CO., LTD. was established in 2002 and become one of the wholly-owned subsidiaries of STEP in 2014. ADTECH specializes in motion control system including motion controller, stepper & servo driver, motor and industry application software and industrial robot that have been sold into over 103 countries and enjoy a good reputation worldwide.
