Hot Selling Products Car Parking One camera with 360 degree for reverse
Product Description:
This is a Monocular 360 panoramic parking assist system, through a single camera installed behind the car, collects the image behind the vehicle during the reversing process, and distorts the image after "image distortion restoration docking technology" -> perspective conversion -> image stitching - > Processing such as image enhancement, eventually forming a panorama. Through the reference information such as the real car model, the driver can easily identify the vehicle position, obstacle distance, surrounding environment and other factors, so as to achieve fast reversing and safe reversing.
Features:
Linux system,running faster and morestable.
User experience is intuitive and reliable,closer to parking.
Support different formats camera input/output:CVBS,AHD
External UART interface,perfect combination with the original Car Host.
Support infrared remote control/button version input for operation and calibration.
Easy installation and simple calibration.
Product highlights
support all kinds of original camera
After the scene restoration,solve the parking blind area
- Vhhicle & Panorama radio display to accurately identify the bottom/border obstacle distance
- Accurate and safe reversing envirement for fast and safe reversing
Main Specifications
| Item | Components | Details |
| 1 | CPU | T3 (Quad Core) |
| 2 | PMU | AXP Allwinner |
| 3 | DDR3 | 1GB SKHYNIX |
| 4 | Nand | Samsung |
| 5 | DC-CD | ROSE |
| 6 | AHD-RX (Optional) | N3 NEXTCHIP |
Parameter Index
| Item | Performance Description | Description |
| 1 | Operating Voltage | DC 9V-16V |
| 2 | Rated Voltage | DC 13.5 |
| 3 | Nominal Voltage | DC 12V |
| 4 | Quiescent current | < 3.0mA |
| 5 | Maximum Current Consumption | < 1A |
| 6 | Operating Temperature | -30 ---+80 Degree |
| 7 | Storage temperature | -30--- +85 Degree |
| 8 | Working humidity | humidity 95%/ temperature 45degree |
