Pigeon Pea Processing Machine Green Peas Processing Plant
- Category: >>>
- Supplier: Shenzhen Xyj Automation Equipment Co. Ltd.
Share on (60820669204):
Product Overview
Description
Pigeon Pea Processing Machine Green Peas Processing Plant
Model | 6SXZ-68 | 6SXZ-136 | 6SXZ-272 | 6SXZ-408 | 6SXZ-612 | 6SXZ-680 |
Output(t/h) | 0.6-1 | 1.2-2 | 2.4-5 | 4-7 | 6-10 | 8-16 |
Carry over Rate(Bad:Good) | >12.5:1 | >12.5:1 | >12.5:1 | >12.5:1 | >12.5:1 | >12.5:1 |
Sorting Accuracy | ≥99.99% | ≥99.99% | ≥99.99% | ≥99.99% | ≥99.99% | ≥99.99% |
Voltage(V/Hz) | 220V 50HZ | 220V 50HZ | 220V 50HZ | 220V 50HZ | 220V 50HZ | 220V 50HZ |
Power Supply(Kw) | 1.0-1.3 | 1.4-1.8 | 2.5-2.9
| 4.8-5.2 | 6.6-7.2 | 8.5-10.5
|
Pressure(Mpa) | 0.4-0.6 | 0.5-0.7 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
Air Consumption(L/min) |
<1000 |
<1800 |
|
<4800 |
<5600
|
<6100 |
Weight |
260kg |
440kg |
820kg |
1180kg |
1620kg |
2200kg
|
Dimension | 950*1510 | 1290*1510*1770mm | 2010*1530*2100mm | 2680*1530*2100mm | 3710*1530*2100mm | 4200*1530*2250mm
|
Product Description
Working Principle
According to the difference in the color of the material, the equipment that automatically sorts the different-colored particles in the granular material.
This product can be used for rice, grains, tea, flower tea, nuts, beans, dehydrated vegetables, dried fruits, seafoods, Chinese herbal medicines, tablets, plastics, ores, metals, precious stones, glass, etc.
Steps
1. Raw Material are put into the machine from its feeding hopper on the top.
2. Vibrated by vibration device and sliding along material chute into the zone of observation in sorting chamber through sensor and background plate .
3. Under the effect of light source, CCD sensor receives compound light from materials being sorted.
4. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve to work ,ejecting the discolor grain to defect chamber and good materials continue to fall into the finished goods chamber.
Why Choose WESORT
1.Over 14 years experiences focus on color sorter. The biggest sorter machine factory in south China. We have the strength give better service and price to you.
2.Overseas Service Station: We have service station, cooperate reseller more than 40 countries. Wesort can meet your requirements on testing, installation and after sales service.
3.OEM/ODM is Supported: We have a strong R&G team(5 famous doctor engineers are included ). We can research and development suitable color sorter for you.
4.Quality Process Assurance: We pass ISO quality management system, each process of production are under strictly standard.
5.Shipping Guarantee: we have professional packaging operations team, independent export qualification to ensure product safety and stability to reach customers in the hands.
6.After-sales Service Guarantee: We provide one year warranty and lifetime maintenance. Free home repair during the warranty period (except for human factors or irresistible natural phenomena caused by failure or damage)
7. Sales team: Our professional sales team is fluent in English, Russian, Chinese , Spanish and Japanese. Can communicate better with customers.
