50 TPD Liquid Potassium Silicate Autoclave Price
- Category: >>>
- Supplier: Shandong Water Glass Mechanical Technology Co. Ltd.
Share on (60820702235):
Product Overview
Description
Product Description
Product Details
The potassium silicate dissolving roller is a kind of equipment that dissolves solid potassium silicate into liquid potassium silicate by means of rotational stirring in a certain temperature and pressure. The working temperature is 150-160° C., and the steam pressure is 0.5-0.6 Mpa.
Feature
1 Applicable for large-scale potassium silicate factory.
2 High efficiency in dissolving high modulus potassium silicate for electrodes
3 The company has made a larger drive optimized design for the roller. With the same solution efficiency, the energy saving rate is reduced by 70%, the transmission is more reliable, the operation is more stable, which will reduce the failure rate greatly, and the motor and the reducer can be effectively protected.
4 Reversible control, frequency speed control, one-key start and stop, data will be uploaded to the central control room, light sound alarm for machine fault .
How to operate
1 Check whether the roller is normal before starting.
2 the solid potassium silicate and water are added into the roller in a certain proportion according to the different specification requirements for different concentrations of liquid sodium silicate, .
3 The roller is heated with steam. After the pressure in the roller reaches 0.6 MPa, stop the steam valve.
4 The density of the material in the roller should be measured frequently. If the concentration of the material is not enough, the roller is continued to rotate until it reaches the specified concentration. If all the materials in the roller are finished, the specified concentration cannot be achieved. The operator adds more materials in the next batch.
5 After the product is qualified, start to discharge. Check if there is any material in the settling tank before discharge to avoid overflow accident after loading.
6 Stop the machine before discharging and open the discharge valve until the discharge is completed.
7 The liquid sodium silicate should be discharged into the vapor-liquid separation tank, and it enters the workshop finished product tank, which is applied by the workshop and passed into the finished product warehouse after passing the quality inspection analysis.
What are the precautions
1 The pressure gauge installed in the trachea must be intact. If the pressure gauge fails, it must be replaced in time.
2 Open the loading cover only when there is no pressure in the roller.
3 The spiral of the feeding cap must be complete, and each time it must be tightly tightened.
4 Check the internal of the roller frequently. If there is any agglutination, clean the roller before dissolving.
5 Avoid blockage of the discharge pipe, discharge pipes, stop valves should be checked frequently to ensure that the valves are complete, safe and reliable.
6 Clean the rollers when stopping or maintenance.
Specification
| Setting Information | |
| Type | horizontal and rotary |
| rated voltage | 380V |
| material | Q345R or customized |
| steam pressure | 0.5-0.6 Mpa |
| working time | 4-4.5 h/batch |
| working temperature | 150-160° C |
| volume | 3,5,6,8,9,10,12,15,16,17,20,25 cbm |
| application | potassium silicate granule dissolving |
Packing&Delivery
FAQ
Q1. What kind of potassium silicate can be dissolved by this equipment?
A: This one is specially for sodium silicate lump, but if for potassium silicate partical( granule), this is also good choice.
Q2. What about the delivery time?
A: It will be 30-40 days after the down payment
Q3. How about the electricity problems?
A: You can tell us your country electricity requirement, will do use the motor as required.
Q4. How do you ship the goods?
A: We usually ship by 20'GP for one equipment, if for 2 sets, it will take a 40'GP, however, we would like to use open top container, because it will be easier and more safe to load and unload.
Q5. How to proceed an order for equipment?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms it and places deposit for formal order.
Fourthly We arrange the production.
Q6. How do you test your equipment before shipment?
A: We will do pressure test before shipment for every equipment
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to our products.
Q8: Can I have my special requirement?
Usually all these equipment are customized, to be based on the premise of scientific design and easy for shipment, the material, the concrete size of the equipment can be as customer requirement.
Q9: How about the installment?
We will give you the detailed installment information, such as foundation drawing, installment drawing, the words, pictures or videos as reference, if you would like our engineer to instruct, you will burden related fees.
