LCD Display 36 inches Paper Cutting Machine Paper Guillotine price

Product Overview

Description





1. Usage: Microcomputer Paper Cutting Machine is used to cut the printing paper of various kinds, paper products, plastic, thin film, leather, slice of non-ferrous metal, etc.

2. 7.8 inch colorful Microcomputer controlled touch screen : It is equipped with imported whole set computer controlling system. The computer has functions as following:the warning for the woring input, self diagnose malfuctions and display the wrong coding. It has 99 programmes, each of them can store 99 cutting s data.

3.Semi-automatic: paper-sending is automatic, but paper-cutting is manual.

4. Double Hydraulic Device:Electromagnetic clutch, more sensitive, improve safety coefficient, the hydraulic system adopts the Germany advanced technology. Equipped with combined hydraulic valve, double hydraulic controlling structure, it approves hydraulic device greatly. The hydraulic device pass CE certificate.

5. Double Guide Device: the paper pusher adopts double imported linear guide and Grinding T shape screw.,which can prolong the machine more precise.

6. Photocell: it is equipped with a photo cell safety protection device.

7. Over load protection device; convenient knife changing device.

8. Worktable chrome treatment: the worktable and side board surface are all adopted chrome treatment to improve the precision and quality of the machine.

9. Air ball: air balls are installed in the worktable. The paper sending work will be easy and accurate.

10. Cutting controller: both of the user’s hands operate the machine. It can cut paper in one time.

11.Electronic knife lock: when the machine is malfunction, the electronic knife lock will lock the knife, and the machine will stop cutting to protect safety.

12. Safety notice : All the safety notice and direction mark is used to cause the safety attention of the user, and do protection and maintenance in time.

Technical Parameter

Model QZYK1370DW QZYK1150DW QZYK920DW

Max cutting width(cm) 137 115 93

Max cutting length (cm) 145 116 110

Max cutting height (cm) 16.5 16.5 13

Max clamping pressure(N) 45000 40000 30000

Cutting speed (cycles/min) 45 45 45

Cutting motor power (kw) 4 4 3

Net weight 4500 4000 2600

Overall dimension (LXWXH)(cm) 289X268X171 267X239X165 217X216X151

Packing dimension(LXWXH)(cm) 300x158x200 265x158x200 229x132x180
