3A zeolite molecular sieve insulated hollow glass sphere adsorbent
- Category: >>>
- Supplier: Nanning Elaiter Environmental Technologies Co. Ltd.
Share on (60822150350):
Product Overview
Description
Product Description
Insulating glass 3A molecular sieve is used to adsorb continuously an amount of moisture from the interspaces, maintains the proper dew point of the space between the inner and outer panes of insulating glass, minimize pressure changes which can eventually leads to distortion of insulating glass or even broken. The product can extend the lifetime of insulating glass unit with low dust, low attrition and low gas desorption to resulting in enhancing the quality, performance, and reliability of insulating glass.
Product Application
1. Specially used for adsorption of the water vapor and organic residues in insulating glass to keep and stabilize dew point of insulating glass.
2. Don’t adsorb sulfur hexafluoride.
Technical Data
Type | Insulating glass molecular sieve | |||
Pore diameter | 3 angstroms | |||
Shape | Bead | |||
Diameter (mm) | 0.5-1.0 | 1.0-1.5 | 1.5-2.0 | 2.0-2.5 |
Static water adsorption (%wt) | ≥20 | ≥20 | ≥20 | ≥20 |
Static N2 adsorption (mg/g) | ≤2 | ≤2 | ≤2 | ≤2 |
Bulk density (g/ml) | ≥0.75 | ≥0.74 | ≥0.73 | ≥0.72 |
Crush strength (N) | ≥8 | ≥14 | ≥20 | ≥26 |
Attrition rate (%wt) | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 |
Temperature rise (ºC) | ≥40 | ≥40 | ≥40 | ≥40 |
Dew point (ºC) | ≤-60 | ≤-60 | ≤-60 | ≤-60 |
Dust (PPM) | ≤30 | ≤30 | ≤30 | ≤30 |
Gas desorption (ml) | ≤50 | ≤50 | ≤50 | ≤50 |
Size ratio up to grade (%) | ≥98 | ≥98 | ≥98 | ≥98 |
Package moisture content (%wt) | ≤1 | ≤1 | ≤1 | ≤1 |
