4040 taper lock bushing metric inch bore bushing
- Category: Bushings >>>
- Supplier: Sichuan Dawn Precision Technology Co. Ltd.
Share on (60822867426):
Product Overview
Description
4040 taper lock bushing metric inch bore bushing
Product Description
4040 Taper Bushing can match with Taper bore belt pulleys,Taper bore timing pulleys, Sprockets and other transmission parts.
4040 Taper bushing Product Structure type
Specifications
Product Name:4040 Taper Bushing
Bore Diameter (Metric system)
| Product Code | Product Model | D1 | D2 | S | D (G7) | b | Js9 | t | Weight (Kg) |
| CP014410 | 4040-26MM | 145.85 | 140.72 | 101.6 | 26 | 8 | ±0.018 | D+3.3 | 10.05 |
| CP014471 | 4040-35MM | 35 | 10 | D+3.3 | 9.86 | ||||
| CP014484 | 4040-38MM | 38 | D+3.3 | 9.78 | |||||
| CP014502 | 4040-40MM | 40 | 12 | ±0.021 | D+3.3 | 9.62 | |||
| CP049546 | 4040-42MM | 42 | D+3.3 | 9.62 | |||||
| CP014515 | 4040-45MM | 45 | 14 | D+3.8 | 9.38 | ||||
| CP014524 | 4040-48MM | 48 | D+3.8 | 9.26 | |||||
| CP014536 | 4040-50MM | 50 | D+3.8 | 9.2 | |||||
| CP014543 | 4040-55MM | 55 | 16 | D+4.3 | 8.87 | ||||
| CP076406 | 4040-58MM | 58 | D+4.3 | 8.6 | |||||
| CP014551 | 4040-60MM | 60 | 18 | D+4.4 | 8.55 | ||||
| CP014557 | 4040-65MM | 65 | D+4.4 | 8.19 | |||||
| CP014561 | 4040-66MM | 66 | 20 | ±0.026 | D+4.9 | 8.1 | |||
| CP014569 | 4040-70MM | 70 | D+4.9 | 7.8 | |||||
| CP014579 | 4040-75MM | 75 | D+4.9 | 7.39 | |||||
| CP014587 | 4040-80MM | 80 | 22 | D+5.4 | 6.89 | ||||
| CP014595 | 4040-85MM | 85 | D+5.4 | 6.46 | |||||
| CP014599 | 4040-88MM | 88 | 25 | D+5.4 | 6.46 | ||||
| CP014608 | 4040-90MM | 90 | D+5.4 | 5.97 | |||||
| CP014616 | 4040-95MM | 95 | D+5.4 | 4.99 | |||||
| CP014620 | 4040-99MM | 99 | 28 | D+6.4 | 4.99 | ||||
| CP014328 | 4040-100MM | 100 | D+4.4 | 4.85 | |||||
| CP049532 | 4040-105MM | 105 | D+6.4 | 4.26 | |||||
| CP049533 | 4040-110MM | 110 | D+6.4 | 3.64 |
Bore Diameter (Imperial system)
Product Category
Package&Shipping
Company Information
Our customers
Our main customers are all world famous brands, like: ABB, s, Sati and a, etc.
Contact us
Summer Wang - 24 hour Service
Skype: summerwang1106
Wechat: +86 18381441297
Your satisfaction is our foremost concern and any inquiry is warmly welcomed.
