Product Overview
Description
High strength abraion resitant steel plates for construction machine
WEL-HARD 500 is one kind of Chinese wear/abrasion resistant steel plates, which is well received in middle east and Africa.WNM500wear-resistant steel was hot rolled and then the plates were heat-treated by direct quenching and tempering and reheat quenching and tempering techniques, respectively. The impact test was carried out with an instrumented impact tester. The micro-structure and fracture surface were investigated by a combination of optical microscopy, transmission electron microscopy and scanning electron microscopy methods. With high mechanical strength,WNM500 is 3 times to 5 times more than common low-alloy steel plates which can significantly improve surface hardness, usually achieved 360 ~ 450HB.
| WEL-HARD 500 | Manufacturer:baosteel | Standard of execution |
|
Executive stantd:Chinese Standard | |||
Shape:sheet plate | |||
Product use | |||
The utility model relates to Thermal power plant (medium speed pulverizer liner, fan impeller shell, dust collector inlet flue, ash duct, bucket wheel liner, separator connection pipe, coal crusher liner, coal hopper and crusher liner, burner, coal hopper and funnel liner, air preheater support tiles, separator guide vane); Groove and funnel lining, hopper bushing, fan blade, pusher bottom, cyclone dust collector, coke guide lining, ball mill lining, bit stabilizer, screw feeder bell and base, kneader bucket lining, ring feeder, dump truck bottom plate; mining machinery (mineral, stone crusher lining, blades) Conveyor lining board, baffle board; construction machinery (loader, bulldozer, excavator bucket board, side blade board, bucket bottom board, blade, rotary drill pipe) | |||
GB | WUYANG | JFE | SUMITOMO | DILLIDUR | SSAB | HBW | Delivery status |
NM360 | WNM360 | JFE-EH360A | K340 | - | - | 360 | Q+T |
NM400 | WNM400 | JFE-EH400A | K400 | 400V | HARDOX400 | 400 | Q+T |
NM450 | WNM450 | JFE-EH450A | K450 | 450V | HARDOX450 | 450 | Q+T |
NM500 | WNM500 | JFE-EH500A | K500 | 500V | HARDOX500 | 500 | Q+T |
NM550 | WNM550 | - | - | - | HARDOX550 | 550 | Q+T |
NM600 | WNM600 | - | - | - | HARDOX600 | 600 | Q+T |
