3VL3725 1AA36 0AA0 circuit breaker VL 250N 3VL3725 1AA36 0AA0

Product Overview

Description

3VL3725-1AA36-0AA0 circuit breaker VL 250N 3VL3725-1AA36-0AA0



Shirley @whxyauto.com   +86-15172506760



circuit-breaker VL 250N without electronic trip unit standard breaking capacity Icu= 55kA / 415 V AC, 3-pole In= < 250 A, rated current with screwed Union connection connections for contact unit and electronic trip unit



Product Description of 3VL3725-1AA36-0AA0 circuit breaker VL 250N 3VL3725-1AA36-0AA0



Shirley @whxyauto.com   +86-15172506760



Product
Article Number (Market Facing Number)	3VL3725-1AA36-0AA0
Product Description	circuit-breaker VL 250N without electronic trip unit standard breaking capacity Icu= 55kA / 415 V AC, 3-pole In= < 250 A, rated current with screwed Union connection connections for contact unit and electronic trip unit
Product Lifecycle (PLM)	PM400:Phase Out Started
PLM Effective Date	Product phase-out since: 01.10.2016
Delivery information
Export Control Regulations	AL : N / ECCN : N
Standard lead time ex-works	5 Day/Days
Net Weight (kg)	1,946 Kg
Product Dimensions (W x L x H)	Not available
Packaging Dimension	132,50 x 246,00 x 123,00
Package size unit of measure	MM
Quantity Unit	1 Piece
Packaging Quantity	1
Additional Product Information
EAN	4011209652088
UPC	Not available
Commodity Code	85362090
LKZ_FDB/ CatalogID	LV10.1
Product Group	3740
Country of origin	Germany
Compliance with the substance restrictions according to RoHS directive	Since: 01.07.2006
Product class	A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation	Yes
Classifications
	Version Classification eClass     5.1   27-37-04-09 eClass     6     27-37-04-09 eClass     7.1   27-37-04-09 eClass     8     27-37-04-09 eClass     9     27-37-04-09 eClass     9.1   27-37-04-09 ETIM       4     EC000228 ETIM       5     EC000228 ETIM       6     EC000228





Similar model codes of 3VL3725-1AA36-0AA0 circuit breaker VL 250N 3VL3725-1AA36-0AA0 for your reference :



Shirley @whxyauto.com   +86-15172506760



3VL2705-1DC33-0AA0, 3VL2706-1DC33-0AA0, 3VL2708-1DC33-0AA0, 3VL2710-1DC33-0AA0, 3VL2712-1DC33-0AA0, 3VL2716-1DC33-0AA0, 3VL3720-1DC36-0AA0, 3VL3725-1DC36-0AA0, 3VL4720-1DC36-0AA0, 3VL4725-1DC36-0AA0, 3VL4731-1DC36-0AA0, 3VL4740-1DC36-0AA0, 3VL5731-1DC36-0AA0, 3VL5740-1DC36-0AA0, 3VL5750-1DC36-0AA0, 3VL5763-1DC36-0AA0, 3VL2705-2DC33-0AA0, 3VL2706-2DC33-0AA0, 3VL2708-2DC33-0AA0, 3VL2710-2DC33-0AA0, 3VL2712-2DC33-0AA0, 3VL2716-2DC33-0AA0, 3VL3720-2DC36-0AA0, 3VL3725-2DC36-0AA0, 3VL4720-2DC36-0AA0, 3VL4725-2DC36-0AA0, 3VL4731-2DC36-0AA0, 3VL4740-2DC36-0AA0, 3VL5731-2DC36-0AA0, 3VL5740-2DC36-0AA0, 3VL5750-2DC36-0AA0, 3VL5763-2DC36-0AA0, 3VL6780-1AE36-0AA0, 3VL7710-1AE36-0AA0, 3VL7712-1AE36-0AA0, 3VL8716-1AE30-0AA0, 3VL6780-2AE36-0AA0, 3VL7710-2AE36-0AA0, 3VL7712-2AE36-0AA0, 3VL8716-2AE30-0AA0, 3VL6780-3AE36-0AA0, 3VL7710-3AE36-0AA0, 3VL7712-3AE36-0AA0, 3VL8716-3AE30-0AA0, 3VL6780-1BF46-0AA0, 3VL7710-1BF46-0AA0, 3VL7712-1BF46-0AA0, 3VL8716-1BF40-0AA0, 3VL6780-2BF46-0AA0, 3VL7710-2BF46-0AA0, 3VL7712-2BF46-0AA0, 3VL8716-2BF40-0AA0, 3VL6780-3BF46-0AA0, 3VL7710-3BF46-0AA0, 3VL7712-3BF46-0AA0, 3VL8716-3BF40-0AA0
