1 кг tungsten бар

Product Overview

Description

1kg tungsten bar   1kg wolfram tungsten rod   1kg raw tungsten bar    tungsten rod   tungsten  bar

high density

Good machinability

High absorption capacity against x-rays



1.Standard: ASTM B760

2.Grade: W1, W2, WAL1, W-Ni-Fe

3.Purity:99.95%min.

4.Density:19.3g/cm3

5.Diameter:3.0mm min.

6.Length:2000mm max.

7.Different sizes are available

8.Applications of tungsten bar:Tungsten bar is generally used to manufacture emitting cathode,  high temperature setting lever, support, lead, print needle and all kinds of electrodes and the quartz  furnace heater.

9.tungsten bar forms and dimensions:





furnished form	specified diameter	min.length
wroughted	2.8<=d<5.0	600
	5.0<=d<6.5	300
	6.5<=d<11.0	200
straightened	0.8<=d<1.0	1000
	1.0<=d<3.0	800
ground	0.8<=d<3.0	800-1000
	3.0<=d<6.5	300-600
	6.5<=d<10.0	200
