24v 300w Waterproof Constant Voltage Led Driver Power Supply for outdoor light
- Category: >>>
- Supplier: Shenzhen Waweis Technology Co. Ltd.
Share on (60825652839):
Product Overview
Description
24v 300w Waterproof Constant Voltage Led Driver Power Supply for outdoor light
| MODEL | IP67 | |||||
| OUTPUT | DC VOLTAGE | 24V | ||||
| OUTPUT POWER | 300W | |||||
| CURRENT RANGE | 0-12.5A | |||||
| RIPPLE & NOISE(max.) | 300mVp-p | |||||
| VOLTAGE ADJ. RANGE | ±10% | |||||
| LINE REGULATION | ±0.5% | |||||
| LOAD REGULATION | ±2.0% | |||||
| VOLTAGE TOLERANCE | ±1.0% | |||||
| CONNECTION TERMINAL | MARK: GND , DC+ | |||||
| SETUP,RISE TIME | 800ms, 50ms at full load | |||||
| HOLD UP TIME | 20ms | |||||
| INPUT | VOLTAGE RANGE | AC190-250V | ||||
| AC CURRENT(Typ.) | 3.1A-2.3A | |||||
| CONNECTION TERMINAL | MARK: FG,AC-L, AC-N, | |||||
| INPUT FREQUENCY | 50-60Hz | |||||
| EFFICIENCY(Typ.) | 88% | |||||
| INRUSH CURRENT(Typ.) | COLD START 30A/230VAC 0.5Ma/230VAC | |||||
| LEAKAGE CURRENT | <0.5mA/240VAC | |||||
| PROTECTION | OVER LOAD | 115%~135% of rated power; Pulsing hicuup shut down, auto recovery | ||||
| OVER VOLTAGE | Rated output voltage of 105%~150% start overvoltage protecion | |||||
Protection: burst mode,load of abnormal conditions removed the automatic recovery | ||||||
| SHORT CIRCUIT | voltage off and reset input for recovers | |||||
| ENVIRONMENT | WORKING TEMP. | -0°C ~ +45°C (Refer to output load derating curve) | ||||
| WORKING HUMIDITY | 20 ~ 90% RH non-condensing | |||||
| STORAGE TEMP.,HUMIDITY | -20°C ~ +85°C 10~95% RH | |||||
| TEMP. COEFFICIENT | ±0.05%/°C | |||||
| COOLING METHOD | BY FREE AIR CONVECTION | |||||
| SAFTY & EMC | SAFTY STANDARDS | CE EN60950-1 Approved | ||||
| WITHSTAND VOLTAGE | I/P-O/P:1.5KVAC, I/P-FG:1.5KVAC, O/P-FG:0.5KVAC | |||||
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG,O/P-FG: 100M Ohms/ 500VDC | |||||
| EMI CONDUCTION | Compliance to EN55022 | |||||
| HARMONIC CURRENT | Compliance to EN61000-3-2,-3 | |||||
| EMS IMMUNITY | Compliance to EN55024 | |||||
| OTHERS | DIMENSION | 250*75*52mm (L'W'H') | ||||
| WEIGHT | 1.8KG | |||||
| SHELL MATERIAL | Aluminum | |||||
Certifications
Company Information
Buyer Feedback
Our Services
1):Before business, reply you within 8 hours all over the world, help you know about our product details and supply the cheapest shipping cost for you.
2):During business, keep you known production schedule on time and check the
details.
3):After Business, we will send you a Feedback Form, which is used to collect our clients` suggestions or advise about our products.
FAQ
1, What kind of company we are?
We are professional power supply manufacturer with high reputation in this field.
2, How we control the quality?
Aging test for 8 hours, after then we put them into the market.
3, Can we accept samples customized?
No problem for samples order, and welcome your testing before your big order.
4, What about the production capacity?
1-2 days for samples order under 10pcs, 7 days for general order under 10000pcs.
5, OEM and ODM are available?
Yes, we accept customized products
6, Will the delivery time be long for a big order?
No, we have two special parts in production line, one for samples orders, another for big orders, so we can control the delivery time as we promise in the contract.
7, What is our warranty service?
For all products we sell have 1 years warranty.
