SS W JH 1mattress computerized multineedle chainstitch quilting machine for comforter and bedding making

Product Overview

Description



HY-W-JH  computerized multineedle chainstitch quilting machine, mattress bedding comforter making machine is specialized in quilting on the mattress, bedding, blanket, etc.



 It is widely used for quilting high-quality mattresses, quilt covers, and household ornaments. Different patterns are available.



Detail Information:



• Needle bar and press plate are controlled by a double- swinging device without cam avoiding lubrication and dirtying of material



• Multi-span and independent patterns(360°and 180°patterns are available)



• Automatic stop motion control in case the top thread or the bottom thread breaks,automatic needle-lifting and CNC speed adjustment



• No need to adjust the press plate' s position when the thickness of quilting material varies



• Outstanding features such as high rigidity, high running speed, low vibration and noise



• CNC precision control system



• Easy preparation of CAD drawings extremely precise



• Strong functions of pattern-combining and multi-span quilting to enable you to quilt different patterns in each row in the mattresses of different sizes



• Fault detection function for ease of determining the running state of the machine at any given time











item	parameter(mm)
Dimension(L*W*H)	4800*1600*2000
Quilting width	2450
Quilting Thickness	80
Space between needle rows	76.2,76.2,152.4(6")
Space between needles	25.4
Quilting speed	200~900rpm
Power	7KW
Voltage	380V/50HZ 220V/60HZ
Weight	4500
