1. Use the double turn plate, double order to forming paper cup. The 600S type machine is an upgrade product that base on single turn plate paper cup machine. The machine adopts open-type, interrupted division design, gear drive, longitudinal axis design. So they can reasonably distribute each part function.
2. The whole machine adopts Spray lubrication, thus reduce the parts abrade, and it adopts Switzerland leister heater for cup body and bottom paper sealing; and silicon oil flow controlled by PLC & electromagnetic valve, in total two course for top curling forming, first course rotate top curling, and second that heating and forming, thus the cup forming will be more perfectly.
3. PLC system controls the whole cup forming process. By adopting photoelectric failure-detecting system and servo control feeding, our paper cup machine’s reliable performance is guaranteed, thus offering a rapid and stable operation. The machine can auto-stop working when there is a failure. Thus it can greatly improve operation safety standard and reduce labor force.
4. Using CCD image detection system (optionally), it will detect the broken, tainted, and molding defects cups. without manual selection it can reduce secondary pollution. 600S intelligent paper cup machine simplifies paper cup forming process, this machine can finish paper feeding, gluing, cup-bottom feeding, heating, knurling, cup-mouth curling, cup-collecting, etc. at one stop. It is especial suitable for making paper cups with a height of 50-135.
