OIC 100S2 Wind Turbine Generator

OIC-100S2 Wind Turbine Generator

Generator:Three phase permanent magnet ac generator
Magnetic steel: NdFeB
Generator case:Carbon steel
Control system:Electromagnet/ wind wheel yaw
Speed regulation:Tail furling
Working temperat:-40 degree to 80 degree
Lurication: Grease injection

Suggest controller: 3kw 120V controller

Suggest Inverter: 3kw 120V inverter

Tower height (m): 9m(3m*3)

Suggest lead acid battery(AH): 150AH 12V*10

Product features
1.Low start up speed, 3 or 5 blades optional for different wind speed areas, high wind
energy utilization
2. Easy installation, tube or flange connection optional
3. Blades using new art of precision injection molding, matched with optimized aerodynamic shape and structure, which enhance the wind energy utilization and annual output;
4. Body of casting aluminum alloy, with 2 bearings swivel, making it survive stronger wind and run more safely,
5. Patented permanent magnet ac generator with special stator, effectively reduce torque well match the wind wheel and generator, and ensure the performance of whole system;
6. Controller,inverter can be matched according to customers' specific needs
