BW300/16 Triplex Piston Mud Pump for Medium Depth Drilling
- Category: >>>
- Supplier: Changsha Miracleland Import & Export Co. Ltd.
Share on (60827427287):
Product Overview
Description
Product Description
BW-300/16 Mud Pump:
BW-300/16 horizontal, triplex, single acting reciprocation piston pump. The pump can choose for motor, it has simple operation, flexible and convenient, can achieve close or remote control. This pump is a compact structure, smooth operation, changing flow range, high output pressure parts, longer life expectancy, stable performance, strength, rigidity and so on.
This pump adopts the car transmission,Can get six different discharge and pressure,Reasonable configuration parameters selection,The construction technology can satisfy different requirements,Mainly used drilling fluid in supply for 2000m about core drilling coal field geology,metallurgy geology,hydrogeololgy,drilling fluid can use mud and water, the coal water etc.
BW-300/16 horizontal, triplex, single acting reciprocation piston pump. The pump can choose for motor, it has simple operation, flexible and convenient, can achieve close or remote control. This pump is a compact structure, smooth operation, changing flow range, high output pressure parts, longer life expectancy, stable performance, strength, rigidity and so on.
This pump adopts the car transmission,Can get six different discharge and pressure,Reasonable configuration parameters selection,The construction technology can satisfy different requirements,Mainly used drilling fluid in supply for 2000m about core drilling coal field geology,metallurgy geology,hydrogeololgy,drilling fluid can use mud and water, the coal water etc.
Technical Parameters
| Type | BW-300/16 Horizontal, triplex, single acting reciprocation piston pump | ||||
| Cylinder bore(mm) | 110 | ||||
| Stroke(mm) | 75 | ||||
| Gears | V | IV | III | II | I |
| Pump speed(min-1) Fast gear | 216 | 171 | 110 | 68 | 37 |
| Discharge(l/min) (l / min) | 300 | 235 | 155 | 95 | 52 |
| Pressure(MPa) | 4 | 6 | 8 | 13 | 16 |
| Pump speed(min-1) Low gear | 161 | 127 | 82 | 50 | 27 |
| Discharge(l/min) (l / min) | 220 | 180 | 115 | 72 | 40 |
| Pressure(MPa) | 6 | 7 | 10 | 15 | 16 |
| Input power(kw) | 30 | ||||
| Suction head(m) | 2.5 | ||||
| Suction Pipe Dia.(mm) | 76 | ||||
| Discharge Pipe Dia.(mm) | 51 | ||||
| Volume(L×W×H) (mm) | 2650×1285×1400 | ||||
| Weight (kg) | 1400 | ||||
BW Series Size Mud Pumps Available:
BW-120, BW-145, BW-150, BW150/1.5, BWZ-150, BW-160, BW160/10, BW-160H, BW-200, BW-250, BW-280/12, BW-280/30, BW300/12, BW-300/12B, BW-300/16, BW-320, BW-350/15, BW-450, BW-450/5, BW-600/10, BW-800/15, BW-1000/12, BW-1500/12, BW-2000/12, BW-2500/16.
Horizontal Directional Drill Series Pumps:
BW-100, BW-150GM, BWF-160/10, BWF-240, BW-250A, BWF-250, BW-320A, BWF-400/10, BWF-600/10.
