MKLB E3 UF/UV/UVF Double Stage RO System RO UP Water Purification Machine Ultra Pure Water Purifier

Product Overview

Description

MKLB E3-UF/UV/UVF Double-Stage RO System RO UP Water Purification Machine Ultra Pure Water Purifier

The machine produces UP water for high-level laboratory using tap water. The water yield per hour is 40-100L, the resistivity reaches up to 18.2MΩ.cm. The machine is completely in conformity with the highest standard for class I water quality of GB6682-2008, ASTM, CAP, CLSI,EP and USP and satisfies the requirements of laboratory water and process water.



Advantages:

--The machine adopts Japanese cold cathode UV sterilizer imported with original packaging, which features as

follows:

1 Alloy electrode, non-filament

2 The service life will not be affected by repeated ON/OFF

3 Longer service life (the maximum life is 50,000h)

4 Smaller volume (pipe diamter: Φ4.0mm, pipe length:150mm)

5 Dual wavelength (185nm & 254nm), thorough sterilization+degradation of TOC

6 With strong vibration strength and unique cuppy electrode, it will not be broken due to impact and can avoid damaing UV tube during transportation and disabling the machine



--1 set of integrated 10L purified module and 1 set of 10L UP module. The system is internally installed with 10L+10L American Dow purified precise resin and nuclear grade resin imported with original packaging. The effluent quality reaches up to 18.2MΩ.cm.



1 The system is switchable between Chinese and English interfaces and is user-friendly. It is equipped with IR remote control, one-key ON/OFF, one-key pure water and UP water intake as well as one-key circulation and washing. Pressure sensor system displays the pressure value of RO film in real time; air joint quick foot switch enables users to get water easily; WIFI module and mobile APP enable IOS and Android users to view online data (optional);

2 Multi-point all-line monitoring and online 3-way monitoring to monitor the quality and temperature of source water, RO water and UP water online;

3 The system can intake water qualitatively and quantitatively at fixed time. Water intake volume can be set as needed and the accuracy reaches ±2ml. The quantitative range is 10-9999ml and the qualitative range is 1-18.2MΩ.cm. True color display screen displays water quality, water volume and flow rate clearly.

4 The system functions on system time setting (Y/M/D/Hr/Min), timed standby (0-60min) and timed shutdown (0-24h).

5 The system collects monitored data in real time and inquires them online. With a storage life of over 1 year, it needs no computer. USBHost interface can be used to export historical alarm record and historical water intake record.



Features:



1 It is an integrated system which produces pure water and UP water using tap water;

2 The controller uses international advanced 32-digit micropower processor as the core and features ultrahigh operating rate and low power consumption. The system adopts advanced EMC design, features strong interference immunity, low noise and strong surge resistance and enables reliable, stable and long-term operation of the controller;

3 The function of automatic and manual washing and circulation extends the service life of American Dow RO film imported with original packaging and reduces bacterial contamination of pure water machine;

4 Resistance constant of conductivity meter: 0.01cm-1, temperature sensitivity: ±0.1°C, automatic temperature compensation;

5 Full-intelligent control system supports multiuser, independent valuation and secondary factory and user password. System settings are all protected by password to avoid unauthorized change;

6 The system functions on online diagnosis of malfunctions (quality of source water, pre-pure water and UP water), warming or auto shutdown, intelligent trouble diagnosis of key components (magnetic valve booster pump, UV lamp and sensor, etc.) and online replacement and indication;

7 Water can be stored in both a pressure barrel and a water tank., The system can display the volume of stored water to satisfy different user needs;

8 The main power supply is 24VDC (low voltage) which conforms to the safety code. ABS engineering plastic housing and water-power separated structure adapt to humid environment, avoid damaging human body and produces ultralow radiation. The pure water pipe and joint have both passed NSF certification;

9 According to operating requirements, various terminal treaters are optional for water intake, which can effectively remove contaminants such as endotoxin, nuclease, ultratrace organics, endocrine disruptor EDS and VOC and satisfy different experimental requirements.





Model	MKLB E3-UF/UV/UVF
System Process	PF+PP+RO+RO+DI+(UV)+(UF)+TF
Water Outlet	2PCS.: Secondary RO water and UP water
Indexes of UP Water:
Influent Requirement*	Urban tap water: TDS<200ppm, 5-45°C, 1.0-4.0Kgf/cm3 (if influent TDS>200ppm, external softener is recommended)
RO Water	Secondary RO water (TDS): 1-5us/cm (conductivity ≤water source conductivity ×2%) Organic rejection rate > 99% (when MV > 200 Dalton); rejection rate of PM and bacteria > 99%
UP Water	E2 series: Conductivity: 16-18.2 MΩ.cm@25°C, heavy metal ion <0.1ppb, bacteria < 0.1cfu/ml, PM (>0.2μm)<1/ml, total organic carbon (TOC) <10ppb*** (UV/UVF type: TOC< 3ppb***), UF/UVF type: heat source < 0.001Eu/ml, ) ribonuclease (RNases)<0.01ng/ml, deoxyribonuclease (DNases) <4pg/ul
Water Yield (25°C)***	10-20L/H
Size/Weight	(W*D*H) 500×400×580mm/ about 38Kg
Power Supply/Power/Noise	220V50HZ/ 50-80W/ <50db
Standard Configuration	Host (including 1 set of purified column) + external 12L pressure barrel + accessory bag
