Description

Vacuum tumbler machine is full 304 stainless steel constructed with reasonable structure, continuous running, low noises, reliable performance, easy operation and high efficiency.

Vacuum tumbling is a method of marinating meat, poultry and seafood and is designed to provide ready-to-cook, value-added products. Suitable for various kind of products such as poultry, fish, pork, beef, etc.

Vacuum tumbler is the equipment based on physical impact principle under vacuum state to realize meat massaging and marinating.

Vacuum rolling and kneading machine can provide a physical process of diced meat energy transformation and indispensable technology of meat processing to accelerate souse speed.Proceed mechanical treatment to diced meat through rolling and kneading and increase the abstraction of salt soluble albuminoidal and improve manufacture product quality.

With abundant saline absorption, the meat structure and water-holding are strengthened; improve vividness of the meat muscles, meat elements, small meat pieces, chicken and elements; the taste and product rate are greatly improved.

Without vacuum tumbling for 20 minutes, marinating requires 24 to 48 hours of soaking before the product is ready for loading into the smokehouse.

Model	JME50	JME100	JME400	JME600	JME1000	JME1200	JME1600	JME2800
Capacity (Kg/Time)	30	50	150-200	225-300	375-500	450-600	600-800	1000
Volume (L)	50	100	400	600	1000	1200	1600	2800
Power (KW)	1.1	1.5	2.25	3	3	3	3.75	4
Speed(r/min.)	6	6	7	7	12	12	8.9/18	12
Vacuum Level(Mpa)	-0.045--0.085
Rated Voltage(v)	220V/380V or Customized
Weight(kg)	50	100	480	520	680	760	980	1500
Dimensions(mm)	800x600 x980	1060x600 x980	1410x1020 x1640	1500x1020 x1640	2000x1020 x1640	2100x1020 x1720	2150x1230 x2000	2500x1540 x2200

Advantages:

1.Making products more juicer,tender and flavorful.

2.Increased profits margins and increased productivity

3.Built-in vacuum system.

4.Clockwise and counter-clockwise rotation

5.Reliable,stable running,low noise & convenient.

6.Most important is easy cleaning.
