The complete juice hot filling production system including:
water treatment system
juice processng systm
juice filling line
packing line
We can supply the complete line and any parts of the line according customer's needs.
General description
This machine is used to fill juice, tea and other non-gas beverage.All the machine part which contact with liquid is high quality stainless steel 304. The relative fittings are from international famous brand.The juice filling machine was equipped with suspension type air conveyor and frequency control of motor speed.This machine is comprised of rinsing, filling and capping system. Rinsing: grip the bottle neck, rotate filling plate, inverse bottle; internal rinsing and external spraying make bottles be cleaned completely. Filling: hot filling with holding bottle neck; the special back flow type of the filling valve can avoid leakage after filling and also control liquid level accurately.Capping: magnetic torque bottle holding type can minimize the cap damage rate and make the capping performance the best.
This machine owns the reasonable, stable and safe design. Under the condition that the bottle neck size is the same, only the output star wheel needs to be changed if bottles are different. It improves the efficiency a lot.
Technical data
MODEL
RXGF14-12-5
RXGF18-18-6
RXGF24-24-8
RXGF32-32-10
RXGF40-40-12
RXGF50-50-15
PRODUCTION CAPACITY(500ML BPH)
2000-2400
4000-6000
6000-10000
10000-15000
15000-20000
20000-24000
FILLING PRECISION
LIQUID LEVEL±2MM
BOTTLE SIZE(MM)
DIAMETER50-100 HEIGHT 150-310
CAP SHAPE
PLASTIC SCREW CAP
WASHING WATER PRESSURE(MPA)
0.2-0.25
GAS CONSUMPTION(M3/MIN)
0.1
0.1
0.4
0.5
0.5
0.6
POWER(KW)
3
4.4
5.2
6.2
7.8
10
WEIGHT(KG)
2000
2800
4500
6000
7000
9500
DIMENSIONS(L*W*H MM)
2080*1560*2130
2360*1830*2250
2900*2200*2250
3880*2200*2250
3700*3000*2350
4500*3500*2400
monoblock
washing filling capping
Packaging & Shipping
Our Services
The sample service we can send you the video of the running machine you are welcome to come to visit our company,and see the machine running in our factory,we can pick you up from the station near our city. If we get the permission of the customer who has brought the machines from us ,we can tell you their contact imformation,you can go to vist their factory.
Customized service we can design the machines according your requirements(materil ,power,filling type,the kinds of the bottles,and so on),at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.
After-sales service we will provide the bill of load on time to make sure you can get the machine quickly when you finish the Preparation conditions ,our engineer will go to your factory to install the machine ,and give you the operating manual ,and train your employee until they can operate the machine well. we provide one year warranty with spare parts free.
Company Information
FAQ
TO BE THE BEST PARTNER OF YOU 1.We are a manufacture. 2.we have been certificated by the famous cercification authority. 3.we have been in beverage packing more than 13 years. 4.we can help you to start a new company in beverage making. 5.we make all of our customers be satisfied with the machine. 6.we will install the machine for you ,and train your employees to use the machine well. 7.we will provide one year warranty with free spare parts.
