FG-4882L-250M series POE switch is designed for PoE power supply. It's designed for PoE power supply work. It's with 8pcs PoE power supply ports and 2pcs uplink ports. The 8pcs PoE ports support IEEE 802.3af/at standard PoE power supply. Single port could reach 30W MAX, 78W max in all. Auto detect IEEE 802.3af/at. Excellent port performance
8pcs 10/100 Madaptive high speed RJ45ports with no network packet loss.
2pcs 10/100Mpbs RJ45 uplink port.
Each port support MDI/MDIXAuto MDI/MDI-X. Support IEEE802.3X Full duplex flow control; Backpressure Half duplex flow control
Exellent PoE power supply performance
Intelligent power management 1~8port with PoE recognition. If device connected is more than IEEE 802.3af standard, it will automatically adopot IEEE 802.3at standard. With IEEE802.3af/at standard, automatically detect and adopt IEEE 802.3af/at standard PD device for power supply, single port could reach 30W.
Flexibility expanding capability
Simple and convenient to use,no configuration required, plug-and-play. Wide compatibility without burning device, high speed transmission, no network packet loss. Easy to expand capacibility to save cost. Meet the demand for high-density PoE power network environment, suitable for home, government agencies, hotels, shopping malls, schools, hospitals and business use to form cost-effective networks.
Specification
Model
FG-4882L-250M
PoE Port
Port 1~4 IEEE802.3af/at
SFP Port
NO
PoE Output
15.4W/30W IEEE802.3af/at
PoE Wire
1/2+,3/6 4/5+,7/8
PoE Consumption
≤120W
PoE Standard
IEEE 802.3af/IEEE 802.3at
PoE Connect
End-Span
POE Transmission
≤250m
Network Standard
IEEE 802.3, IEEE802.3u,802.3x,802.3af/at
Network Media
10/100BASE-TX: CAT5 or above UTP-Unshielded Twisted Pair
Network Distance
Transmission≤250m (Support VLAN)
Backboard bandwidth
1.6Gbps
Forwarding mode
Store and Forward
Forwarding rate
10BASE-T:14880PPS/port
100BASE-tx:14800pps/port
MAC ADD
1K MAC Address list
Port Function
IEEE802.3X Full duplex flow control; Backpressure Half duplex flow control
