12 каналов 100 м 433 МГц DC 9 24 в беспроводной передатчик приемник в дистанционном управлении

1, Technology parameter:

Operating Voltage:  DC9-24V

Operating temperature:-40C~+80C

Contact current:≤10A

Sensitivity:≥-105dBm
working  Frequency: 315/433MHz/optional

Memory:30(learning and fixed code)

2.Feature:

  popular appearance design in the world

  interlocking,latching,momentary,6 way latching and 6 way momentary optional

  working with learning code

  With super-heterodyne receiver module,sensitivity:-105dB

  Terminal and connector optional


 III. Methods and steps for learning and clearing code
Learning code & fixed code:
Press "Learning" button on the receiver, release it until LED light goes out, Receiver
in learning status (LED flickers this moment), then press related button on Remote
control to monitor this Receiver. When LED on Receiver flickers 1 time and keeps
for a long while, it indicates Learning has been done. It can learn about as much as
30 pieces of Remote control of the same mode.
If Remote control is lost and wanting to make it invalid totally, press "Learning" button
(more than 3s) until LED light flickers,then Receiver will eliminate all contents automa-
tically. If want to reuse it, just learning one more time again.

Application

1.Wireless home security system
2.Car sunroof remote control
3.Vehicle central locking system
4.Wireless call system
5.Home appliance / industrial automation
6.Electronic garage door / gate opener
7.Remote toy control
8.Remote fan / lighting control
9.Wireless motor-driven curtain
10.Heating systems
11.Wire elimination project

Packing and Price Information



Shipping ways

Exhibiton Show

Company Information:

Shenzhen Yaoertai Technology Co., Ltd. is a highly specialized company, founded in 2005. Our company specializes in the design, development, manufacture and marketing of such RF products as wireless receivers and transmitter modules, wireless remote controls, car alarm systems, home alarm systems and related accessories. We provide both OEM & ODM services.

Our product quality can meet FCC, CE, and RoHS standards. With strong technology, we have produced more than 1,00 types of quality products, which are available to different sectors and can meet a variety of special needs of customers throughout the world. Our products are exported to Australia, Latin America, Southeast Asia, North America, the Middle East and Europe.

Certification
