Factory Use High Speed Moon Cake Machine Mooncake Making Machine
- Category: Baking Equipments >>>
- Supplier: Shanghai Yucheng Machinery Co. Ltd.
Share on (60829625609):
Product Overview
Description
Automatic Mooncake Filling&Forming Production Line
Technicial Data
| Model | Machine | Capacity | Product Weight |
| YC-168 | Automatic mooncake making machine | 20-120PCS/min | 10-200g |
| Power | Voltage | Dimension | Weight |
| 1.5KW | 220V / 380V | 1670*920*1290mm | 310KG |
| Material | Ratio of Crust and Filling | Payment Terms | |
| SUS 304 | 0:10 --- 2:8 | 50% T/T as deposit,balance before shipping. | |
Features.
1.20-120pcs/min,1.5times faster than similar machine.
2.Error of each product within 1g, and we will have the improvements every year.
3.Easy to operate the machine, you can handle the machine with 3 hour training.
4.All the electric components adopt the one stop solution provided by DELTA, such as PLC, invertor.
5.The machine can memory the recipe, just need to adjust the parameters one time for single product.
6.Available for various kind of food, including the loaf bread, burger bread, filled bread, whole wheat bread,etc.
7.It is designed for factory.
8.Material adopt SUS304, food grade type.
9.Easy to disassembly the parts, and cleaning the machine need a little time.
Multifunctiple Application
By Change different molds, YC-168 can used to produce more than 100 kinds of foods.
Compontnts Used
| Electronic Components List (YC-168 Encrusting Machine) | |||
| Components | Amount | Brand | Remarks |
| Invertor | 5 | DELTA |  |
| Screen | 1 | DELTA | |
| Wire for Invertor(3 meter) | 1 | DELTA | |
| PLC Controller | 1 | DELTA | |
| Power Switch | 1 | MEAN WELL |  |
| Cutter Motor | 1 | OTT |  |
| Dough Hopper Motor | 1 | OTT | |
| Filling Hopper Motor | 1 | OTT | |
| Conveyor | 1 | OTT | |
| Flour Sprayer Motor | 1 | OTT | |
| Speed Changer | 1 | OTT | |
| Intermediate Relay | 1 | CHINT | |
| Breaker | 1 | CHINT | |
| A.C. Contactor | 1 | CHINT | |
Aftersell Service
Shanghai Yucheng machinery CO., LTD. warrants that machines and components are manufactured under strict quality control to assure normal operation. The warranty period is one year from the date of arriving at port. During the warranty period, the machine components (excluding consumable parts) will be repaired or replaced without any charge. Only the first purchaser is entitled to the warranty. Well preserving documents with the date of arriving at port is highly recommended. If the machine component is repaired or replaced during the warranty period, the warranty period is not renewable because of the repaired / replaced accessory component.
