Hot sell flake ice machine in malaysia with 3.0t capacity

Share on (60829856702):


Price:

Quantity:


Product Overview

Description


flake ice machine in malaysia



Product Description


1. Large contact area:
As its flat and thin shape, it has got the largest contact area among all types of ice. The larger its contact
Area is, the faster it cools other stuff. In comparison with 1 ton of cube ice, 1 ton of flake ice has 1799 sqm
Of contact area while 1 ton of cube ice only has 1383 sqm, therefore the flake ice has got much better cooling effects than cube ice.
2. Low cost of producing:
The producing of flake ice is very economical, it only requires 1.3rt refrigerating effect to make 1 ton of ice from 16c water.
3. Perfect in food cooling:
Flake ice is type of dry and crispy ice, it hardly forms any shape edges, in food cooling process, this nature has made it the best material for cooling, it can reduce the possibility of damage to food to the lowest rate.
4. Thoroughly mixing:
Flake ice can become water quickly through the rapid heat exchanging with products, and also supply the moisture for products to be cooled.
5. Convenient for delivery:
Because the flake ice fairly dry, it will not stick with others during delivery or storage.


Small freshwater flake ice machine in malaysia parameters
































































































































 Model

 Output capacity


(Ton/day)


 Refrigerant

 Run Power


(Kw)



 Operating Weight


(Kg)



 Demention


(mm)



 Ice starage room volume


(KG)



 Ice storage room demention


(mm)


 XF-0.3T0.3 R4041.8 250900*900*700 150900*900*1000

 XF-0.4T


 0.4  R404 2.3  300 1200*900*700  300 1200*900*1000
 XF-0.5T 0.5  R404 2.4  380 1200*900*700  300 1200*900*1000
 XF-0.6T 0.6  R404 2.8  420 1200*900*700  300 1200*900*1000
 XF-0.8T 0.8  R404 3.5  500 1200*900*900  300 1200*900*1000
 XF-1.0T1.0 R4044.45501200*900*9003001200*900*1000
 XF-1.2T1.2 R4045.56001200*900*9004001200*900*1000
 XF-1.5T1.5 R4047.97001300*1100*10005001300*1100*1200
 XF-2.0T2.0 R4048.78501300*1100*11005001300*1100*1200
 XF-2.5T2.5 R4049.89501300*1100*12005001300*1100*1200
 XF-3.0T3.0 R40411.512001700*1400*130010001700*1400*1500




flake ice machine in malaysia


1. The temperature of ice is lower and it can reach 8 Celsius degree below zero


2. Ice is dry and transparent, good looking shape, non-caked, good mobility and sanitary.


3. It has the flake shape so that it has big contact area with refrigerating products and the effect is excellent.


4. Flake shape and no sharp edges, cannot destroy refrigerating products and it is beneficial for storage and transportation.


5. The thickness of flake ice is 1mm-2mm. No need to crush and can use at any time.


 flake ice machine25.jpg


Flake ice is  flat in shape, which can be applied to seafood cooling, meat processing and industrial procedure. The most important use of Snowkey flake ice is concrete cooling, especially in hot climate. Though the flake ice is cooled down slightly-7, it is still a kind of dry ice, which means its heat quantity is potential and the main source of cooling energy can be 100% guaranteed. Since it is a kind of dry ice, the cooling input of flake ice can be calculated accurately and the temperature effect to the concrete mixture is obvious. Flake ice is movable freely. They will not stick together, and condense to lump. Therefore, flake ice is convenient to store and transport. Because of the above features and moderate production cost, flake ice is greatly applied to many industries and food processing.



flake ice machine packing.jpg


flake ice machine13.jpg


flake ice1.jpg


Flake Ice MachineFeatures:



1.Internally-scraping ice skate can help reduce energy consumption and prevent leakage of refrigerant



2.Stainless steel materials , advanced processing equipment and heat treatment ensure the best heat transfer efficiency



3.The design of the large water receiving plate can prevent water leaking at the bottom of drum



4.Photoelectric switch is directly installed in bottom of evaporator



5.Direct liquid feeding and dry evaporation --simple , safe and reliable control



6.Integrated modular equipment installation is convenient for maintenance


Flake Ice MachineAdvantages:



1.Irregular ice flakes with size about 40 x 40 and thickness around 1.5-2.5 mm



2.The thin ice can be directly used for strring and mixing refrigerated materials



3.No acute edges and corners so it will not damage the surface of the cooled object ; Iceflakes are as cold as below -8 °C



4.Large contact area and good mobility can ensure their full contact with refrigerated objects to realize good preservation effect



5.Easy to crush and mold



6.The ice flake machine is small-sized , light and convenient for use anytime





 timg (8)


flake ice4.jpg


flake ice machine.jpgflake ice machine5.jpgflake ice machine19.jpgflake ice machine39.jpg


If you are interested in our products, please contact us. We would be very glad to be on service for you. As the most professional ice machine manufacture in China, we are pleased to do our best offer to open a good market for you. We are definitely to contact you within 3 days after getting your inquiry.








Our Services





1. Reply your enquire in 24 working hours.


2. Experienced staffs are able to answer all your questions in profesional and fluent English.


3. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.


4. Different kind of customized tube ice machines are available. All reasonable suggestions are welcome.


5. Overseas service center availale and engineers available to service machinary overseas.


6. Supply the flake ice machine of high quality.





Packaging & Shipping


1. Standard wooden case.
2. Completely ice machine contain: machine, cover,cooling tower, water pump, water pipes and water pipe fittings.
3. Machine come into use, customer only need prepare power for the machine.
4. All required components for installing the machine will be provided.
5. Our factory also can produce cold room for store ice.





Other :




1. The payment can be T/T,L/C,Western Union, Money Gram and in Cash.
2. The deposit is 30%, after we receive your deposit, we will start to produce the machine for you. The balance 70% should be paid before shipping.
3. The delivery time normally is 30 days after receive the deposit.


Attention:


The price is for reference only, do not do the actual transaction.


Our prices are based on customer's specific requirements,so the specific amount should be addressed by further discussion.
