Hydraulic drilling machine 180M Geothermal Water Well Drilling Machine Rig Drilling Machine Kw180
- Category: >>>
- Supplier: Quzhou Kaipu Machinery Equipment Co. Ltd.
Share on (60829934026):
Product Overview
Description
Products Information
Modle | KW180 |
Weight(KG) | 4500 |
Dimensions(mm) | 4600mm×1550mm×2350mm |
Travelling speed(km/h) | 0~2.5 |
Hole Diameter | Φ115-202mm |
Drilling Hardness | f=8-12 |
Air Consumption | 19-30m3/min |
Applicable Hammer | 4/5/6 inch |
Drill Rod Diameter | Φ76/Φ89mm |
Engine modle | YC4DKC4G2-80 (58kW/2200rpm) |
Power | 58Kw/2400rpm |
Climb capacity(°) | 20 |
Drilling depth(m) | 180 |
Working pressure(Mpa) | 1.05-2.46 |
Air consumption(m3/min) | 16-30 |
Leng of rod(mm) | 2000 |
Drill bit diameter(mm) | 110-202 |
Feed cylinder stroke(mm) | 400 |
Feed power(N) | 25000 |
Lift power(N) | 50000 |
Speed of rotator(rpm) Min speed | 33 |
Speed of rotator(rpm) Max speed | 67 |
Lifting speed(m/min) Min speed | 8 |
Lifting speed(m/min) Max speed | 26 |
Fltting speed(m/min) Min speed | 0-15 |
Fltting speed(m/min) Max speed | 51 |
Rotation torque(N.m) | 4200 |
Application of air compressor water well drill machine
KW180 is punctured equipment for light, efficient, versatile, it is mainly applied to bore hole drilling wells, geothermal air conditioning hole and other uses.
Advantage of air compressor water well drill machine
KW180 is punctured equipment for light, efficient, versatile, it is mainly applied to bore hole drilling wells, geothermal air conditioning hole and other uses.
Advantage of air compressor water well drill machine
\t\t\t\t\t\t\t\t\tMain Products \t\t\t\t\t\t\t
\t\t\t\t\t\t\t\t\tCompany Information \t\t\t\t\t\t\t
Our company is located in Quzhou City, Zhejiang Province, which is in the central area of China with convenient transportation and the economic center of Zhejiang. Our company has many years' experience in the business of air compressors and drilling rig machines.
Our company provide more than 20 kinds products, which including piston air compressors, screw air compressors, drilling rig machines, drill bits, drill rods, DTH, air picks, rockdrills, down the hole drills, small mining piston air compressors, chiller air compressors, and concretespraying machines. Meanwhile, we own independent rights of import and export. Our products have a vast marketin foreign countries, and are exported to Southeast Asia, South America, Africa and many other countries and regions, Our company has been committed to providing good after-sale service and best quality to meet domestic and overseas users demands.
\t\t\t\t\t\t\t\t\tCertificate \t\t\t\t\t\t\t
\t\t\t\t\t\t\t\t\tExhibition \t\t\t\t\t\t\t
\t\t\t\t\t\t\t\t\tPacking and Shipping \t\t\t\t\t\t\t
\t\t\t\t\t\t\t\t\tFAQ \t\t\t\t\t\t\t
Q1: Are you factory or trade company?
A1: We are factory. And we have ourselves trading company.
Q2: What the exactly address of your factory?
A2: Our company is located in JNo.9 Kaixuan Ave West, Economic ZoneQuzhou, Zhejiang, China
Q3: Warranty terms of your machine?
A3: One year warranty for the machine and technical support according to yourneeds.
Q4: Will you provide some spare parts of the machines?A4: Yes, of course.
Q5: What about the voltage of products? Can they be customized?A5: Yes, of course. The voltage can be customized according to yourequirement.
Q6: Which payment term can you accept?
A6: 30% T/T in advanced, 70% T/T against the B/L copy.
Q7: How long will you take to arrange production?
A7: 380V 50HZ we can delivery the goods within 7-15 days. Other electricity orother color we will delivery within 25 30 days.
Q8: Can you accept OEM orders?
A8: Yes, with professional design team, OEM orders are highly welcome.
Q9: Which trade term can you accept ?
A9: Available trade terms: FOB/ CIF/ CFR/ EXW, etc.
