Comica UHF 48 channels wireless microphone 1 receiver and 2 transmitters for camera, camcorder

Product Overview

Description

Comica UHF 48 channels wireless microphone 1 receiver and 2 transmitters for camera, camcorder



Description:

WM100 Plus is a wireless microphone with dual-transmitter triggered by one receiver, with two AA batteries. It utilizes UHF wireless FM technology and LCD high-resolution lattice screen, 16-level adjustable volume, and is integrated into LCF(Low cut filter) , Auto IR Channel-match, Stereo / Mono switchable audio mode, RF signal strength adjustment, MIC/LINE IN input dual selection, Power monitoring at receiver end, Sound pickup dynamic display, Backlight adjustment and other functions, at the same time with strong shielding anti-noise performance, it’s a high-quality microphone to broadcasting level;



Main features:

. 1-trigger-2,Perfectly Support Two Transmitters and One Receiver Work Simultaneously

. Working Distance Up to 100m (Open Area 100m, 60m in area with obstacle)

. 48-channels for Multiple Devices Work Together

. M/S Switch, IR Sync, LCF, 16-levels Adjusted Gain Control, Muting Functions

. Two Power Supply Modes(AA batteries and support external charging)

. Support Real-time Monitor

. Volume Dynamic Monitor

. Adjusted RF Power

. Lattice LCD Display, High Resolution



Specification:

Hand-held Transmitter HTX

Channel	48
Duration	6 Hours
Signal/Noise	>65dB
Antenna	PCB Antenna
Stray Radiation	<-60dBc
Sound Delay	<20ms
Audio Distortion	<0.5%
Battery	AA batteries×2pcs
Size	Φ 53.5(max)x253mm
Operating Temperature	0℃ ~ +50℃
Storage Temperature	-20℃ ~ +60℃



Lavalier Transmitter TX

Channel	48
Duration	6 Hours
Antenna	1/4 Wavelength Wire Antenna
Stray Radiation	<-60dBc
Sound Delay	<20ms
Audio Distortion	<0.5%
Signal/Noise	>65dB
Audio Input Socket	3.5mm Socket
Battery	AA batteries×2pcs
External Power	Micro USB 5V/1A
Group	A / B
Size	107 x 66 x 26.1mm
Operating Temperature	0℃ ~ +50℃
Storage Temperature	-20℃ ~ +60℃



Receiver RX

Channel	48
Duration	6 Hours
Signal/Noise	>65dB
Antenna	1/4 Wavelength Wire Antenna
Sensitivity	-90dBm
Sound Delay	<20ms
Audio Distortion	<0.5%
Wireless Frequency	20Hz~18KHz
Audio Output Socket	3.5mm Socket
Battery	AA batteries×2pcs
External Power	Micro USB 5V/1A
Size	107 x 66 x 26.1mm
Operating Temperature	0℃ ~ +50℃
Storage Temperature	-20℃ ~ +60℃
