8D-FB cable joint connector n male straight crimp type

Description.

N-type is a middle and small power connector with threaded connection, whose characteristic impedance can be classified into 500 and 750 two kinds. They have high reliability, shock resistance, excellent mechanical and electrical performance characteristics. It is widely used in radio equipment, communications equipment, microwave test and ground launch system connector RF coaxial cable in vibration and harsh environment. It uses high-precision semi-rigid semi-flexible cable, whose frequency can go up to 11GHz, and get smaller voltage standing wave ratio.




Product Information.


Item No.: NM-YD8H-G08

Connector Type: N
Installation method: crimp type
Matching cable: 8D-FB

Gender: male
Size: as drawing


Drawing.

\t
Interface
\t
According to
\t
IEC 61169-54
\t
Electrical
\t
Impedance
\t
50 ohm
\t
Frequency
\t
DC-3GHz
\t
VSWR
\t
≤1.2
\t
Dielectric withstanding voltage
\t
≥2500V RMS, 50Hz, at sea level
\t
Dielectric Resistance
\t
≥5000MΩ
\t
Center contact resistance
\t
≤1.0m Ω
\t
Outer contact resistance
\t
≤1.0m Ω
\t
Mechanical
\t
Mating cycles
\t
≥500 times
\t
Apply with the cable
\t
8D-FB
\t
Material and plating
\t
Body
\t
Brass / Ni plating
\t
Center conductor
\t
Phosphor bronze / Ag plating
\t
Dielectric
\t
PTFE
\t
Other
\t
Brass / Ni plating
\t
Environmental
\t
Temperature range
\t
-40℃~+85℃
\t
Watertightness
\t
IP67
\t
Rosh-compliance
\t
Full Rosh-compliance
\t
Salt-fog test
\t
96h
