Digital salinity sensor for sea water RO system And Conductivity Salinity 420ma Electrode Probe Conductivity Sensor
- Category: >>>
- Supplier: Nanning Nobo Instrument Co. Ltd.
Share on (60830815928):
Product Overview
Description
Product Description
Digital conductivity/salinity sensor is a new generation of intelligent water quality monitoring sensor which research&developed by our factory .Using high performance CUP Chip to measure the conductivity and temperature .Support to check the data , debugging and maintenance by mobile APP or computer.It has the advantages of easy maintenance, high stability, excellent repeatability and multi-function, which can measure conductivity value in liquid exactly . It is widely used to online monitor the conductivity value in liquid in thermal power generation,chemical fertilizer,metallurgy,environmental protection , pharmacy , biochemistry, food and tap water .
Detailed Images
Main Features | ||||||
◇Digital Conductivity /salinity sensor , 4-20mA or RS485 signal output directly | ||||||
◇High Accuracy , high stability , strong anti-jamming | ||||||
◇It can connect to the internet of things , PLC and other equipment which has Rs485/4-20mA signal interface to collect data and maintenance without instrument .It is convenient for users to integrate sensors into industrial control environment ,such as ,upper computer system and the internet of things . | ||||||
◇By using the mobile phone app, the sensor can be collected, debugged and maintained by the wireless network (such as WIFI/ GPRS) or wired network ( OTG line and 485 / USB module) | ||||||
◇The sensor can be set up by RS485 communication , slave address , baud rate,online calibration ,recoverable factory setting , 4-20ma output range(4-20mA is optional ), coeffcient of proportionality and incremental compensation | ||||||
◇Using three points calibration method | ||||||
◇Power off protection >10 years | ||||||
Technical Parameters | ||||||
◇Measuring range :0~300‰ ◇Resolution:0.1‰ ◇Accuracy :2.0 %(FS) ◇Automatic temperature compensation:0~100℃ Temperature compensation:NTC10k ◇485 interface :Support to the internet of things (MODBUS Protocol partial compatibility) ◇Working condition:Environmental temperature 0-60℃ ◇Input impedance:≥1×1012Ω ◇Output load:4-20mA load <500Ω(optional ) ◇Working voltage : DC 5V or DC 12V or DC24V ◇Protection grade :IP68 | ||||||
Packing & Delivery
Product Name: Digital Conductivity /Salinity sensor | Brand Name: NOBOTECH | ||||
Model Number: NS-CD301 | Place of Origin: Nanning, China | ||||
Delivery Time: 7 to 15days after payment | |||||
WHY CHOOSE US
Nanning Nobo Instrument & Meter Co., Ltd. is a high-tech enterprise integrating design, research and development, production, sales and service. It focuses on independent research and development of intelligent water quality analysis instruments and Internet of Things technologies. cloud service. Products include PH / ORP, conductivity, dissolved oxygen, residual chlorine, ozone, ion concentration, turbidity, salinity, sludge concentration, COD, ammonia nitrogen and other water quality analyzers, water quality digital sensors, DTU, Nobo cloud. The company integrates Nobo artificial intelligence, big data, and cloud technology to build a smart Internet of Things platform to provide customers with multi-parameter water quality monitoring systems, promote smart cities and smart agriculture, and promote industry changes.
The company's new concept of science and technology - "technology changes life", "people-oriented, customer first" as a principle of service, "innovation, professionalism, unity, integrity, dreams" as the company's five core values.
The company has advanced research and development institutions (artificial intelligence laboratory and physical and chemical laboratory), industry-leading SMT production line, advanced production technology, and excellent talent team. The company has passed ISO9001:2015 quality management system certification. The company adopts 5S standardization management as the standardization system of the company. The company exchanges and cooperates with national key laboratories of many famous universities to promote technological development. The company's products are of stable quality, advanced technology and complete functions. They are favored by domestic customers and exported to North America, Europe, Southeast Asia and other overseas places.
With the development of the times and markets, the company has transformed from a traditional water quality analyzer manufacturer into a high-tech enterprise focusing on digital sensors, intelligent water quality analyzers, water quality monitoring systems, artificial intelligence, Internet of Things, and big data services.
Contact us
E-mail:sales@nobowisd.com
Tel:+86-771-3812343
Web:www.nobowisd.com www.nobowisd.net
Tel:+86-771-3812343
Web:www.nobowisd.com www.nobowisd.net
FAQ
Q: How do you guarantee the quality?
A: Firstly, we have our own factory with strong R&D center and QA team which can totally make sure the quality of every single product. Secondly, we have a completed after-sale service .
Q: Is OEM available?
A: Yes, all goods can be customized according to your requirements, including packing, LOGO print, etc.
Q: Can it buy only 1 set of the meter?
A: Yes. No matter how many products you buy, we are grateful all along.
Q: How to deliver the goods for trial order or small order?
A : At customer's request ,we prefer to choose international express, such as DHL, EMS.TNT.Fedex.
