  • short circuit & earth fault indicator TRMS Voltage GFCI RCD Tester Circuit Analyzer
short circuit & earth fault indicator TRMS Voltage GFCI RCD Tester Circuit Analyzer
short circuit & earth fault indicator TRMS Voltage GFCI RCD Tester Circuit Analyzer
short circuit & earth fault indicator TRMS Voltage GFCI RCD Tester Circuit Analyzer

short circuit & earth fault indicator TRMS Voltage GFCI RCD Tester Circuit Analyzer

Share on (60831947899):


Price:$38.00

Quantity:


Product Overview

Description


circuit analyzer

general instructions:

This circuit analyzer is a special test device designed for AC low-voltage distribution line quick fault location. With simple operation, accurate measurement and other features, it can detect multiple problems on a line, such as causing to electric shock, electrical fire. abnormal operation of equipment, etc.

Product Description

HT-5908A--Circuit Analyzer


feature
--data storage
--Quickly check the correct wiring
--Identifies proper wiring in 3-wire receptacles
--solve faulty splices and connections,
--solve incorrect wiring
--solve undersized wiring
--solve faulty GFCIs
--solve faulty or incorrectly wired AFCIs
--solve incorrect line voltage
--solve poor ground quality
--TRMS AC voltage measuremen
--ower quality monitor

Functions
--TRMS measuring AC voltage
--Artificialload 12A, 15A, 20A measuring line drop
--Measuring phase voltage, neutral line (zero line )voltage to earth, peak voitage, frequency
--Measuring phase (live line). neutral line (zero line ).earth line conductor impedance
--ldentifying 3-wire socket connection mode (zero for left and live for right, having earth line or not)
--Test the reliability of residual current device (RCD) and response action time
--Test the reliability of GFCI action and response action time
--Backlight function and data hold function


\t
Specifications
\t
Range
\t
Resolution
\t
Accuracy
\t
Line voltage
\t
85.0~135.0V
\t
0.1V
\t
±(1.0%+2)
\t
Peak Line Voltage
\t
120.0~190.0V
\t
0.1V
\t
±(1.0%+2)
\t
Voltage with Loading equipments
\t
10.0~135.0V
\t
0.1V
\t
±(2.5%+2)
\t
Line frequency
\t
45.0~65.0HZ
\t
0.1HZ
\t
±(1.0%+2)
\t
Impedance-live and Neutral & Earth
\t
0.00~3.00Ω
\t
0.01Ω
\t
±(2.5%+2)
\t
\t
>3.00Ω
\t
0.01Ω
\t
NO ensure
\t
Neutral-Ground Voltage
\t
0.0~10.0V
\t
0.1V
\t
±(2.5%+2)
\t
RCD trip time
\t
1ms~6.5S
\t
1mS
\t
±(1.0%+2)
\t
RCD trip current
\t
30mA~37mA
\t
0.1mA
\t
±(1.0%+2)
\t
GFCI trip time
\t
1ms~6.5S
\t
1mS
\t
±(1.0%+2)
\t
GFCI trip current
\t
6mA~9mA
\t
0.1mA
\t
±(1.0%+2)
\t
Voltage drop
\t
0.1~99.9%
\t
0.1%
\t
±(2.5%+2)
\t
Voltage drop load current
\t
12/15/20A
\t
General
\t
Power supply
\t
6*1.5V AAA Batteries
\t
Product size
\t
194mm*78mm*37mm/7.64"*3.07"*1.46"
\t
Product weight
\t
254g/0.56lb
\t
Certificate
\t
CE/ETL/RoHS
\t
Safety rating
\t
CAT III 300V
\t
Accessories include
\t
Power cord
\t
\t
Carry bag
\t
\t
Battery and user´s manual
\t
Detailed Images


1,show those information form transmitter
2,accurate and durate
3,Identify breakers and fuses
4,built-in AC/DC detecting function
