Hot Selling Mimaki UJF A3FX/UJF 3042FX UV Flatbed Printer

Product Overview

Description





UJF-3042FX ensures that you can respond to your clients requirements for single or short run digital printing enhancing a multitude of products (including molded items), substrates and media up to 50 mm thickness with personalised messages.



UJF-3042FX
Head	On-demand Piezo head
Print resolution	720 × 600 dpi, 1,440 × 1200 dpi
Ink	Hard UV curable ink : LH-100, LF-140, LF-200
Ink capacity	220 ml ink cartridge / 600 ml ink pack
Inkjet primer	PR-100 (220 ml ink cartridge / 600 ml ink container)
Maximum print width	Width : 300 mm (11.8 "), Length : 420 mm (16.5 ")
Media	Width	Width : 364 mm (14.3 "), Length : 463 mm (18.2 ")
Thickness	Max. 50 mm (1.97 ")
Weight	Less than 5 kg (11 lbs)
Set device	Air suction by vacuum
UV device	Equipped with UV Light Emitting Diodes
Interface	USB 2.0
Applicable standard	VCCI class A, FCC class A, UL, RoHS Directive, CE Marking
Power specifications	AC 100 - 240 V (Automated voltage conversion)
Power consumption	Less than 350 VA
Operational environment	Temperature	20 - 35 °C (68 - 95 °F)
Humidity	35 - 65 % Rh
Dust	Equivalent to normal office level
Weight	Approx. 113kg (249.1 lbs.)
Dimensions (W x D x H)	1,200 mm x 1,090 mm x 770 mm (47.2 " x 42.9 " x 30.3 ")
