single passenger lift
- Category: Elevators >>>
- Supplier: Lingzhi Elevator Co. Ltd.
Share on (60836246478):
Product Overview
Description
single passenger lift
Product Description
Company Information
Our Services
| Loading Capacity | Door | Door | Car | Hoistway Size (mm) | Machine Room | |||
| Rated Speed (m/s) | Opening | Opening type | Size (mm) | Size (mm) | ||||
| Passengers | Size (mm) | |||||||
| (JJ×HH) | (AA×BB) | AH×BH | PP | OH | (W×D×H) | |||
| 450kg/ | 1 | 800×2100 | Center Opening | 1400×850 | 2000×1550 | 1500 | 4500 | 2500×3200×2500 |
| 6 Passengers | 1.5 1.75 | 1600 | ||||||
| 630kg/ | 1 | 800×2100 | Center Opening | 1400×1100 | 2000×1750 | 1500 | 4500 | 2500×3600×2500 |
| 8 Passengers | 1.5 1.75 | 1600 | ||||||
| 800kg/ | 1 | 800×2100 | Center Opening | 1400×1350 | 2000×2000 | 1500 | 4500 | 2500×3800×2600 |
| 10 Passengers | 1.5 1.75 | 1600 | ||||||
| 1000kg/ | 1 | 900×2100 | Center Opening | 1600×1400 | 2200×2150 | 1500 | 4500 | 3000×4000×2600 |
| 13 Passengers | 1.5 1.75 | 1600 | ||||||
| 1250kg/ | 1 | 1100×2100 | Center Opening | 2000×1400 | 2600×2150 | 1500 | 4500 | 4000×4500×3000 |
| 16 Passengers | 1.5 1.75 | 1600 | 4700 | |||||
| 1350kg/ | 1 | 1100×2100 | Center Opening | 2000×1500 | 2600×2250 | 1500 | 4500 | 4000×4500×3000 |
| 18 Passengers | 1.5 1.75 | 1600 | 4700 | |||||
| 1600kg/ | 1 | 1100×2100 | Center Opening | 2000×1750 | 2600×2500 | 1500 | 4500 | 4000×4500×3000 |
| 21 Passengers | 1.5 1.75 | 1600 | 4700 | |||||
FAQ
1. Installation & Maintaining & Technical Support.
Re: We will send installation & maintaining manual along with the elevator in the container.Our suggestion is to hire a professional local company for installation and future maintaining,once you need any technical assistant from us, just don't hesitate to contact us by mail or phone.Technician will be sent to the job site if necessary.
2. The Spare Parts & Guaranty
We will provide you the free spare parts delivered along with the container.
If any parts get damaged due to quality issue within 18 months after B/L date. We will send new replacement once confirmed.
