Motorized screw jack can also be called Electric screw jack, which includes a worm gear screw jack and an electric motor. The Motorized Jacks have higher efficiency than manual screw jack. There are two types worm gear screw jack for motorized screw jacks, they are self-locking machine screw jack or high precision ball screw jack. The motor can be a high-precision servomotor, stepping motor, geared motor, worm gear reducer, bevel helical gearmotor, worm helical gearmotor, three-phase motor, or single phase motor, and 12v, 24v, 48v Brush or Brushless DC motors and DC gear motors, etc. Note: If it is a electric ball screw jack, a brake motor or an external locking device is required to maintain the position. Electric screw jacks offer the most economic solutions for a wide range of industrial applications and the load capacity up to 100-ton as standard.
Three Structures (Connection) for Motorized Screw Jacks:
1. Structures 1 (Foot Mounted): input shafts(worm), coupling, and B3 foot mount motor.
2. Structures 2 (Flange Mounted): screw jack with motor flange, and B5, B14, or NEMA flange motor.
3. Structures 3 (Flange Mounted): screw jack with motor flange, coupling, and B5, B14, or NEMA flange motor.
Mechanical screw jacks can be operated by manually or by electrical motor. More than one screw jacks can be connected together to move simultaneously.
Screw jack is used in applications where linear motion is required. Lifting of any load, pushing or pulling of mechanical equipment, adjusting of tight clearances of mechanical parts can be done by screw jacks. Mechanical capacity of screw jacks is between 2.5kN and 1000kN. Jack screws can be used as linear motors, linear actuators, or mechanical lifts depending on type of motion.
Main components of screw jacks are: trapezoidal lifting screw, worm screw, worm gear and gear housing. Worm screw is rotated manually or by motor. Worm gear is rotated by worm screw. The lifting screw moves through the rotating worm gear. The linear motion speed of lifting screw depends on thread size and rotation ratio of worm gears.
100kN motorized screw jacks with nut for electric jacking system. Cubic electric lifting screw jack load capacity 100 kN, self locking ACME screw diameter 55mm, pitch 9mm, upright mount, rotating screw type, stroke 500mm, ratio 36:1 (one rpm input travel length 0.25mm), plain end, right shaft and left motor adapter, attached bronze lifting nut, double bellows boots, flange block bearing, and 4 kw brake motor with B14 motor flange.
50KN electric worm gear screw jacks lifting device with three-phase two-speed motor. Motorised screw jacks 50 KN load capacity with a compact and versatile cubic housing, self locking Trapezoidal screw diameter 40 mm, pitch(lead) 7mm, upright mount, travelling screw type, stroke 1500mm, ratio 7:1 (one rpm input travel length 1mm), threaded end and rod end bearing, left side motor flange and right input shaft(worm). Accessories include three-phase two-speed motor(Y100L-8P/4P-0.85KW/1.5KW, 480V/60HZ/3PH), protective pipe, rod end and proximity switches.
Modular and compact cubical design 2.5 ton motorized screw jack provides maximum adaptability to each specific application. For this motorized jack with dc 24v worm gear reducer features: short stroke 50mm, top plate(flange) end, vertical mount, translating design, slowest ratio 1/24, trapezoidal screw Tr 30 x 6, left input shaft(worm) and right motor adapter. Accessories: dc 24v motor attaches RV30 worm gearbox, motor flange, and protective tube.
Cubic design 25KN electric worm screw lift mechanism offers modern aesthetics and versatile mounting on two faces of the gearbox, while eliminating the need for upright and inverted variants. For this motorized jacks, upright mount, translating screw type, stroke 500mm, slowest gear ratio 24:1, self locking ACME screw diameter 30 mm, pitch(lead) 6mm, thread end combines with rod end as one, left input shaft(worm) and right motor adapter. Accessories: dc 24v motor with vertical mount(motor flange), protection tube, bellows boots and rod ends.
10ton electric motor drive actuator worm jack reducer features: maximum static load capacity 10 tons, worm screw 58 mm diameter, pitch 12mm, stroke 75 mm, highest ratio 1/8, inverted type jack, no rotation keyed screw design. Accessories: 0.75kw worm gear motor reducer, motor flange, limit switches, protective tube, and plain end.
25 ton electric actuator features: The motor is parallel mount with spindle, suitable for limit space. Maximum static load capacity 25 tons, lifting screw 90 mm diameter, pitch 16mm, stroke 900 mm, slowest ratio 1/32, inverted type jack, translating screw design. Accessories: 4kw three phase 380V AC motor with gearbox, motor flange, clevis end, and protection tube.
25kn electric traveling nut screw jacks features: worm screw 26 mm diameter, pitch 5mm, stroke 1000 mm, slow gear ratio 1/24, vertical lifting, travelling nut rotating design, attached copper lifting nut, flange block bearing, motor flange, and 0.75 kw motor.
5 Ton Screw Jacks with Induction Motors Features: maximum static load capacity 5 tons, worm screw 40 mm diameter, pitch 7mm, stroke 150 mm, slowest ratio 1/6, upright, no rotation keyed screw design. Accessories: 1.1kw bevel-helical gear motor, incremental encoder, motor flange, limit switches, protective tube, and non standard top plate end.
2.5 ton 24vdc jack screw features: maximum static load capacity 2.5 tons, worm screw 30 mm diameter, pitch 6mm, stroke 900 mm, highest ratio 1/6, upright type jack, translating screw design, clevis end. Accessories: 24v gear motor, motor flange, dc motor controller and protective tube.
5 ton electric worm gear screw jack with lifting nut for heavy duty screw jack lift systems. Strong electrically screw jack load capacity 5 ton, self locking ACME screw diameter 38mm, pitch 6mm, inverted mount, rotating screw design, stroke 900mm, ratio 1/24 (one rpm input travel length 0.25mm), plain end, right input shaft and left motor adapter. Attached 3-phase electric motor with bevel-helical gearbox, and copper travel nut.
10 tonne 220v single phase motorized electric screw lift features: maximum static load capacity 10 tons, worm screw 58 mm diameter, pitch 12mm, stroke 1500 mm, highest ratio 1/8, inverted type jack, travelling screw design. Accessories: 1.5kw 220VAC single phase motor with bevel gear reducer, motor flange, rubber bellows, protective tube, and top plate end.
2.5 tonnes worm electric screw lift jacks (cubic design) are high quality engineering products for precise lifting, lowering and pivoting of loads, and are, under normal operation, maintenance free. This motor jack is in a trunnion mounting arrangement, the screw has a pivot on the end and the jack body is mounted on a large pivoting frame, or trunnion. This type of mounting is particularly common in the antenna industry. In practice, the pivot should be as close to the centerline of the internal nut as design permits. Its features cover acme lead screw Tr 30x6, stroke 600 mm, highest ratio 1/6, vertical lifting, travelling screw design, attached proximity switches, bellows boots, rod ends, protect covers, and trunnion mounting feets.
5 tonne three phases electric motor screw jack with rv worm gear reducer features: maximum static load capacity 5 tons, worm screw 40 mm diameter, pitch 7mm, stroke 75 mm, highest ratio 1/6, inverted type jack, no rotation keyed screw design. Accessories: 0.75kw motor with rv worm gear reducer, motor flange, limit switches, protective tube, and plain end.
Electric powered screw jack 20 tons(200 KN) load capacity with a compact and versatile cubic design gearbox, self locking ACME screw diameter 70 mm, pitch(lead) 10mm, upright mount, travelling nut type, stroke 1200mm, ratio 10:1, plain end, right side motor flange. Accessories include 4kw AC motor 415V/50HZ/3PHASE, and bronze travelling nut.
2 ton motorized travel nut rotating screw lift jack for screw drive systems adjustment. Motorized screw drive jack load capacity 2tons, self locking ACME screw diameter 26mm, pitch 5mm, upright mount, rotating screw design, stroke 900mm, ratio 20:1 (one rpm input travel length 0.25mm), plain end, left shaft and right motor adapter, attached copper travel nut, and DC 24V motor.
5ton motor operated screw jack for motorised power the lifting systems. Motorized screw lift load capacity 5 ton, self locking ACME screw diameter 38mm, pitch 6mm, upright mount, travelling screw type, stroke 500mm, ratio 24:1 (one rpm input travel length 0.25mm), rod end, right side motor flange, attached 1.5 kw three phase motors with 90-B5 motor flange.
Electric screw jack 2.5t with worm gear reducer
Stainless Steel Motorized Screw Jack 5ton Inverted with Clevis End
5 ton Precision Screw Jack with Servo Motor
Electric operated screw jack 100KN load capacity with a compact and versatile cubic design gearbox, stroke 1500mm, ratio 36:1, self locking ACME screw diameter 55 mm, pitch(lead) 9mm, upright mount, translating screw design, clevis end, right side motor flange and left side input shaft. Accessories include 1.5kw geared motor with USA 3-phase voltage, protective tube and screw bellows boots.
A screw jack is a device used to apply a force, push and pull, or move to a position and hold by mechanically converting rotary motion into linear motion.
* Screw jacks (Mechanical actuators) capacities from 1/4 ton to 100 tons
* Available in machine screw, ball screw, stainless steel machine screw actuators, micro-miniature actuators, motorized machine screw and ball screw actuators, electric cylinders and motor control systems
* Accessories include miter gear boxes, c-face motor adapters, limit switches, transducers, visual and digital position indicators, couplings, ball screws and ball screw systems, and locking rings
* Can be used as alternatives to hydraulic and pneumatic systems.
Worm gear screw jack or worm screw jack is a mechanical motion control device used for lifting heavy weight objects, push or pull an object. The key components of screw jacks are trapezoidal lifting screw, worm screw, worm gear and gear housing. Worm screw is rotated manually (manual screw jack) or by a motor (electric screw jack).
Motorised screw jack driven motor types include electric motor, gear motor, gear reducer, hydraulic motor, pneumatic motor, explosion proof motor. Motor means asynchronous/induction motor and above motor no brake, if need,marked in purchase order/invoice.
Motorised screw jack suitable powers cover 1/8HP(90W), 1/6HP(120W), 1/4HP(180W), 1/3HP(250W), 1/2HP(370W), 3/4HP(550W), 1HP(750W), 1.5HP(1.1KW), 2HP(1.5KW), 3HP(2.2KW), 4HP(3KW), 5.5HP(4KW), 7.5HP(5.5KW), 10HP(7.5KW). Input power larger than 7.5KW contact JACTON sales/engineers.
Motorised screw jack pole numbers include 4 poles and 6 poles. Under 4 poles motor, standard output 1500rpm-50hz, 1800rpm-60hz. Under 6 poles motor, standard output 1000rpm-50hz, 1200rpm-60hz. For gearmotor or gear reducer output RPM = electric motor output RPM / reduction gear ratio. Electric screw jack Lifting speed = final output RPM x travel length per full turn of input shaft.
Motorised screw jack allowable voltage,phases and hertz includes 380V-3 Phases-50HZ, 220V-3 Phases-50HZ, 400V-3 Phases-50HZ, 415V-3 Phases-50HZ, 440V-3 Phases-50HZ, 480V-3 Phases-50HZ, 220V-3 Phases-60HZ, 240V-3 Phases-60HZ, 480V-3 Phases-60HZ, 110V-Single Phase-60HZ, 120V-Single Phase-60HZ, 220V-Single Phase-50HZ, 230V-Single Phase-50HZ, 240V-Single Phase-50HZ. For special application, for example solar tracker industry, most of engineers or designers prefer to use 24V, 36V, 48V DC motor with gear reducer direct connected worm gear screw jack.
Motorised screw jack mounting type includes b3 foot mounting, b5 flange mounting and b14 face mounting. Suitable IEC motor frame sizes 56, 63, 71, 80, 90S, 90L, 100L, 112M, 132S, 132M.
Screw Jack System is usually used for lifting heavy duty load or lifting platform. Screw Jack System mainly includes screw jack, bevel gearbox, electric motor, connecting rod coupling, gear reducer. Clients can choose 2 screw jacks system, 3 screw jacks system, 4 screw jacks system, 6 screw jacks system, 8 screw jacks system for your practical application. We can offer a complete screw jack system including electric motor, gear reducer and so on. Before clients place orders, our engineers provide 2D CAD or 3D drawings for final confirmation. Note: When the screw jacks travel stroke is too long, we advise the clients to use a guide post.
