ER316L TIG Weld Filler rod,ER316L Stainless steel TIG welding rod
ER316L TIG Weld Filler rod,ER316L Stainless steel TIG welding rod
ER316L TIG Weld Filler rod,ER316L Stainless steel TIG welding rod
Product Detail
| MIG diameter | 0.8mm 0.9mm 1.0mm 1.2mm 1.6mm |
| TIG diameter | 1.6mm 2.0mm 2.4mm 3.0mm 3.2mm 4.0mm |
| Raw material | stainless steel alloy |
| Packing 1 | D100-1kg |
| Packing 2 | D200-5kg |
| Packing 3 | D300-15kg |
| S-k-y-p-e | zander.welding.industry |
| MOQ | 100 kgs |
| Delivery | 5-7 days |
| Product Keywords | Stainless Steel TIG rod sticks 3/32 |
ER316
Description: ER316 is TIG welding wire for stainless steel. The weld metal is austenitic structure containing 19%Cr-12%Ni-2%Mo, which is excellent in corrosion resistance, heat resistance and crack resistance. Because Mo contains good corrosion resistance to acetic acid, sulfurous acid, phosphoric acid and salts, especially against chloride ion pitting.Uses: Used for the welding of the same type of stainless steel, but also for the welding of high-chromium steel and dissimilar steel without heat treatment after welding.
Item | C | Si | Mn | P | S | Cr | Ni | Mo | Cu |
Standard | ≤0.08 | 0.30- | 1.00- | ≤0.030 | ≤0.030 | 18.00- | 11.00- | 2.00- | ≤0.75 |
Test | 0.048 | 0.43 | 1.78 | 0.012 | 0.010 | 19.23 | 12.5 | 2.52 | 0.30
|
ER316L
Description: ER316L is a TIG welding wire for ultra-low carbon stainless steel. The weld metal is austenitic structure containing 19%Cr-12%Ni-2%Mo, which is excellent in corrosion resistance, heat resistance and crack resistance. Because Mo contains good corrosion resistance to acetic acid, sulfurous acid, phosphoric acid and salts, especially against chloride ion pitting.Uses: Used for welding welding of urea and synthetic fiber equipment. It can also be used for welding high-chromium steel and dissimilar steel without heat treatment after welding.
Item | C | Si | Mn | P | S | Cr | Ni | Mo | Cu |
Standard | ≤0.030 | 0.30- | 1.00- | ≤0.030 | ≤0.030 | 18.00- | 11.00- | 2.00- | ≤0.75 |
Test | 0.022 | 0.42 | 1.89 | 0.009 | 0.007 | 19.12 | 12.62 | 2.62 | 0.34 |
