Main Features
Output Power:3W
Frequency Range: 136-174MHz/400-480MHz
199 Memory Channels
Scan
PC Software Programmable,Manual Programming,Wire Copy
VOX Function
CTCSS/DCS
Monitor, Reverse Frequency
Power Saving Function, Low Power Warning
High/Low Power Selective
Emergency Alarm
Whispering Function
Busy Channel Lock
Transmitter Time-out Timer(TOT)
Side Key Assignment
0-9 Grades Squelch Level Setting
Group Calls
Calling Remind
LCD Display
Chinese and English Voice Prompt
FM Radio (87.5-108MHz)
200mAH Li-ion Battery
GENERAL | |
Frequency Range | 136-174MHz/400-480MHz |
Operating Temperature | -20℃ to +55℃ |
Frequency Combination | please lock frequency synthesize |
Frequency Stability | ±2.5ppm |
Memory Channel | 199 |
Working voltage | 3.7V |
Antenna Impedance | 50Ω |
Operating Mode | simplex of co-frequency or alien |
Dimensions | 122*60*38mm |
Weight | 232g |
TRANSMIT PART | |
RF power | 3W |
Modulate Mode | F3E |
Max.Freq.Deviation | ≤5KHz |
Remain Wave Radiation | <-60dB |
Transmitting Current | ≤1000mA |
RECEIVER PART | |
Sensitivity | <0.20uV (12dB SINAD) |
Squeich Sensitivity | <0.20uV |
Intermodulation Antijamming | 50dB |
Audio Power output | 500mW |
Receiving Current | ≤100mA |
Squelch Stangby | 20mA |


Lead time:
Sample:1-3 working days
Wholesales order: 500PCS within in 5-7 days;
OEM order:7-15 days after receiving your deposit and confirm sample & package design.
Shipping:
Express: door to door service DHL,UPS,FEDEX,TNT and so on.
By air: To destination airport, need to assist clear customs, without door to door service.
By sea:To destination port, need to assist clear customs, without door to door service.
Tips:
The shipping cost depends one weight and dimension, will recommend the cheapest and safest way according your detail quantity.
Shipping period depend on your location. If deliver by express,it take 3-7 days from China to destination country. Some remote need more 1-3 days.
FAQ
1. What is MOQ(Minimun order quantity)?
we recommend you order 2pcs for sample test that would be better.
2. Do you accept customized?
Yes,we can design the packing box and LOGO mark as your request,OEM&ODM is welcomed.
3. Could you offer free sample to test?
In general, customers need to pay the sample fee first, but when your order reach required amount, we refund the sample cost for you.
4. When can you ship the items?
1-2day for sample,3-30days for bulk order, depends on the quantity.
5. When can I find tracking information on internet?
Usually,we will give you the tracking number and you can find the information on internet in 2 days.
6. How do you ensure your quality?
Before delivery, we will check the items' quality strictly one by one,life-warranty for radio host & accessories, but we could not ensure some unpredictable reason occured,please contact us immediately.
