Sealed type 2v 800ah solar gel 48v 24v deep cycle solar battery

Share on (60837257138):


Price:$190.00

Quantity:


Product Overview

Description


Sealed type 2v 800ah solar gel 48v 24v deep cycle solar battery

Hot selling models

solar battery 12V 100.PNG  solar battery 12V 150.PNG  solar battery 12V 200.PNG  Tubular gel OPzV 2V.PNG




GEL Battery 2V
Sealed type 2v 800ah solar gel 48v 24v deep cycle solar battery



CG2-800
Nominal Voltage 2V(Single Cell)
Design Floating Life @ 25℃ 20 Years
Nominal Capacity @ 25℃ 10 hour rate @80.0A,1.8V 800Ah
Capacity @ 25℃20hour rate (42.4A,1.8V )848Ah
5 hour rate (141A,1.75V )705Ah
1 hour rate (484A,1.6V )484Ah
Internal Resistance Full Charged Battery @ 25℃≤0.26mΩ
Ambient TemperatureDischarge-20℃~60℃
Charge -10℃~60℃
Storage -20℃~60℃
Max.Discharge Current@ 25℃ 1600A(5s)
Capacity affected by Temperature (10 hour )40℃ 102%
25℃ 100%
0℃ 90%
-15℃70%
Self-Discharge @25℃per Month 3%
Charge (Constant Voltage) @ 25℃Standby Use Initial Charging Current Less than 120A Voltage 2.23-2.27V
Cycle UseInitial Charging Current Less than 120A Voltage 2.33-2.37V
Dimension (mm*mm*mm)Length 410±1 * Width 175±1 * Height  330±1 (Total Height 366±1)
Weight (kg) 52±3%




Product Description

Characteristics

CG SERIES LONG LIFE DEEP CYCLE GEL BATTERY

Voltage: 2V

Capacity: upto 2V3000Ah

Designed floating service life: 15~20 years at 25 °C/77 °F.



Summary for deep cycle solar battery 2V

CSPOWER deep cycle GEL battery is designed for frequent cyclic charge and discharge applications under extreme environments. By combining the newly developed Nano Silicone Gel electrolyte with high density paste, the Solar range offers high recharge efficiency at very low charge current. The acid stratification is highly reduced by adding Nano Silicone Gel.

GEL  Structure

Features for telecom battery, Long life GEL Battery

1. This stationary battery comes with a superior gel electrolyte where sulfuric acid is evenly mixed with silica fume and acid layering does not exist.

2. The electrolyte is gel like and immobile, which enables no leakage and uniform reaction of battery plates.

3. Serving as perfect power supply equipment, the front access lead acid battery is designed with slim shape. Front access terminal connection is convenient for installation and maintenance, and space serving.

4. Radial type grid design and tight assembly technology enable prominent high rate discharge performance for our GEL VRLA battery.

5. Due to a unique design, the electrolyte volume of this battery can not reduce in use, and it requires no watering during service life.

6. Special anti-corrosion grid alloy is utilized so that the energy storage device comes with more than 12years of design life at 25degree.

7. High purity raw materials ensure super low battery self discharge.

8. Thanks to the use of gas recombination technology, our industrial battery boasts extremely high seal reaction efficiency and yields no acid mist, thus friendly and pollution-free to the environment.

9. By means of special design and high reliable sealing technology, the battery is well sealed, thus ensuring definite safety.

100 Solar battery structure.PNG



deep cycle gel solar cell battery 2V800ah for power storage

QC/ Certification

200 Solar battery qc.PNG

201 Solar battery  Certification.PNG





Application

300 Solar battery application.PNG






Application of Long life Deep cycle GEL Battery 2V

Communication equipment, Telecommunication control equipment;

Emergency lighting systems;

Electric power systems; Power station; Nuclear power station;

Solar powered and wind powered systems;

Load leveling and storage equipment;

Marine equipment; Power generation plants; Alarm systems;

Uninterruptible power supplies and stand-by power for computers; Medical equipment; Fire and security systems; Control equipment; Stand-by electric power.
