The Advantage of a Steel Framed Parking Garage How to build a Car Parking Structures

Product Overview

Description

The Advantage of a Steel Framed Parking Garage How to build a Car Parking Structures

* Products&Service Scope:

Design&Engineering Service, Steel Building, Space Frames, Portable Cabins, Tubular Steel Structures, basic building elements(built-up welded H-section, hot-rolled H-section, channel, steel column, steel beam), standard frames, secondary framing, roof & wall materials, Tempcon (sandwich) panels

* Engineering Design Software:
AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures(Xsteel)V12.0. Etc



Product Description:

Item	Materials	Remark
Steel Frame	1.H section column and beam	Q345 steel, paint or galvanization
	2.wind resistant column	Q345 steel,paint or galvanization
	3.Roof purline	Q235B C/Z section galvanized steel
	4.Wall purline	Q235B C/Z section galvanized steel
Supporting system	1.Tie bar	Q235 round steel pipe
	2.knee brace	angle steel  L50*4,Q235
	3.roof horizontal bracing	φ20,Q235B steel bar, paint or galvanized
	4.column vertical bracing	φ20,Q235B steel bar, paint or galvanized
	5.purline brace	Φ12 round bar Q235
	6.knee brace	angle steel, L50*4,Q235
	7.casing pipe	φ32*2.0,Q235 steel pipe
	8.gable angle steel	M24 Q235B
Roof and wall  protecting system	1.Wall and roof panel	corrugated steel sheet/sandwich panel
	2.self tapping screw	M5.5*50
	3.Ridge tile	color steel sheet
	4.gutter	color steel sheet/galvanized steel/  stainless steel
	5.down pipe
	6.corner trim	color steel sheet
Fastener system	1.Anchor bolts	M24 Q235 steel
	2.Bolts	4.8S / 8.8S /10.9 S  Galvanized
	3.Nuts	Galvanized
