Multifunctional dust collector fm300 high quality
- Category: >>>
- Supplier: Henan Bailing Machinery Co. Ltd.
Share on (60838556655):
Product Overview
Description
Product Description
BLQM series air box pulse bag type dust collector is a new type of high efficiency dust removal equipment developed by our company based on the technical experience deposited over ten years. The filter bags of the full range of products are 130 mm in diameter and 2,450 mm in length and 3060 mm in length, which facilitates the replacement of wearing parts. In addition to the ordinary type, the bag material is also available in high temperature type and waterproof.
⌈ Filter area ⌋:93-1767 m²
⌈ Air volume ⌋:6690-133900 m³/h
⌈ Application range ⌋:Widely used in dust purification operations in various industries such as building materials, metallurgy, electric power, and chemical industry. |
Principle
Parameters
| Model | Air volume(m³/h) | Total filter area(m²) | Chamber(pcs) | Quantity of filter bag(pcs) | Total quantity of filter bag(pcs) | Number of pulse valve(pcs) | Blowing pressure(Mpa) |
| BLQM96-4 | 26800 | 372 | 4 | 96 | 384 | 4 | 0.5-07 |
| BLQM96-5 | 33400 | 465 | 5 | 96 | 480 | 5 | 0.5-07 |
| BLQM96-6 | 40100 | 557 | 6 | 96 | 576 | 6 | 0.5-07 |
| BLQM96-7 | 46800 | 650 | 7 | 96 | 672 | 7 | 0.5-07 |
| BLQM96-8 | 53510 | 744 | 8 | 96 | 768 | 8 | 0.5-07 |
| BLQM96-9 | 60100 | 836 | 9 | 96 | 864 | 9 | 0.5-07 |
| BLQM32-3 | 6690 | 93 | 3 | 32 | 96 | 3 | 0.5-07 |
| BLQM32-4 | 8930 | 124 | 4 | 32 | 128 | 4 | 0.5-07 |
| BLQM32-5 | 11160 | 155 | 5 | 32 | 160 | 5 | 0.5-07 |
| BLQM32-6 | 13390 | 186 | 6 | 32 | 192 | 6 | 0.5-07 |
| BLQM64-4 | 17800 | 248 | 4 | 64 | 256 | 4 | 0.5-07 |
| BLQM64-5 | 22300 | 310 | 5 | 64 | 320 | 5 | 0.5-07 |
| BLQM64-6 | 26700 | 372 | 6 | 64 | 384 | 6 | 0.5-07 |
| BLQM64-7 | 31200 | 434 | 7 | 64 | 448 | 7 | 0.5-07 |
| BLQM64-8 | 35700 | 496 | 8 | 64 | 512 | 8 | 0.5-07 |
product advantages
1.Box-type cleaning, better effect
Air box pulse bag type dust collector adopts separate chamber to clean dust, when cleaning, separate by box, take turns. The pulse and cleaning cycle of each chamber is automatically and continuously performed by the cleaning program controller according to a preset program, thereby ensuring the effect of compressed air cleaning.
2.More product specifications, dust collection efficiency of 99.9%
There are 33 specifications of air box pulse bag filter products, and there are 32, 64, 96 and 128 bags in each room. The length of the dust bag is 2450 mm and 3060 mm and the dust collection efficiency can reach 99.9% or more. The dust concentration of the purified gas is less than 100 mg/m³.
3.Unique structure to extend the life of the filter bag
The entire box body is designed with the inlet and outlet main pipe structure, and the ash hopper can extend under the inlet main pipe to allow the incoming dusty flue gas to directly enter the expanded ash bucket to achieve the pre-dusting effect. The advantages of integrated chamber backflushing and jet pulse cleaning increase the service life of the filter bag.
Our Services
One-Stop-Service for Your Project
7 x 24 h online service
1. Pre-sale services:
Act as a good adviser and assistant of clients
(1) Select equipment model;
(2) Design and manufacture products according to clients' special requirement;
(3) Train technical personnel for clients;
2.Services during the sale:
Respect clients; considering every aspect and details for our customers
(1) check products ahead of delivery;
(2)keep costumers informed about the delivery process
3. After-sale services
We promise excellent after-sale service!
(1) Assist clients to prepare for the first construction scheme;
(2) Install and debug the equipment;
(3) Train the first-line operators on site;
(4)Take initiative to eliminate the troubles rapidly at site;
(5)Provide maintenance for big items.
And other rational requirement brought up by our clients.
FAQ
Q: 1.Are you factory or trade company?
A:We are factory.
Q: 2. To which country your products have been exported before?
A: Our products have been sold to America, Brazil, Chile, Sudan, Zambia, Kenya,Turkey, Indonesia,Malaysia, Philipines, Australia, India and so on.
Q: 3. How will you help the customer install the equipment?
A: Our senior engineer will guide the installation and commissioning as well as the initial production at
Q: 4. How about the wear parts supply?
A: We offer wear parts to our customer with our most favorable price. If there are problems youcould not handle, we will send our technicians to your place and you are therefore, responsible for all thecost involved.
Q: 5.What about the payment method?
A:T/T, Paypal, Western Union, L/C is available
Q: 6.What about the Shipment?
A:We'll choose proper transportation mode based on the weight of goods, usually arrange shipment such as DHL,FEDEX,TNT or UPS.
Q: 7.What about after-sale service?
A:12 months warranty for all kinds of products;
