Solar Energy System,Flat Roof Adjustable Solar Panel Mount Solar Power System

Product Overview

Description

 Solar Energy System,Solar Power System,Flat Roof Adjustable Solar Panel Mount Solar Power System

This is an real innovative mounting system.All parts can be pre-fabricated into only one module.
The  installation is extremely labor-saving and low-cost, no need adjusting, no sawing in the field. Just need an cordless screw-deiver.



Key features:
   1.Extremely fast,low-cost and labor-saving;
   2.Modular designed,pre-assembled in factory;
   3.Self-adjustment, adaptable to rooftop unevenness≤5°
   4.Flexible layout,adapt to complicate rooftop
   5.Self-grounding,reduce grounding wire and lug
   6.Can be applied in large and small scale solar energy project
   7.Material: Aluminum Alloy&Stainless Steel



Product Specification:

Roof Type	Flat roof
Material	AL6005 &SS304
PV Type	With or without frame
Module Orientation	Horizontal or vertical
Surface Roughness	B&C
Wind Speed	<60m/s
Snow Load	<1.4KN/M2
Warranty	20years





---All solar mount type solution component:

Roof Mount		Common Components
Seam Roof	Roof Clamp	Aluminum Rail	Mid Clamp	End Clamp	Earthing Washer	Earthing Lug Core	Rail Splice Kit	Roof Screw
Tile Roof	Roof Hook	Aluminum Rail	Mid Clamp	End Clamp	Earthing Washer	Earthing Lug Core	Rail Splice Kit	Roof Concrete
Flat Roof	Foot	Aluminum Rail	Mid Clamp	End Clamp	Earthing Washer	Earthing Lug Core	Rail Splice Kit	Roof Concrete
Carport	Post	Purlin Rail	Mid Clamp	End Clamp	Earthing Washer	Earthing Lug Core	Rail Splice Kit	Steel



Company Information

Solar Master Tehcnology Co.,Ltd is a company specializes in PV system design and consulting service, and provide solar mounting system solutions. The company has the experienced system and structural engineers, combining domestic and overseas advanced design ideas and project management experience, to optimize the solar systems and to generate the most competitive quotation and solutions. The products of SMT are all in accordance with the national & international quality stand design, test, production. Fullfilling and Satisfying the customers' needs are always we seek for. The engineering team of SMT can provide PV system design and construction consulting, project technicial proposal, on-site supervision service.

The SMT is dedicated to the research and development for the solar ground & roof mounting systems and solar carports. We have launched a series of innovative solar mounting solutions. The goal of the structures is safety and reliable, easy installation, convenient and cost-saving.
