ARC 300DS 1P 220V IGBT Module Inverter DC water proof arc welder, wide voltage 95 295V welding machine 20 300A Copper Cable
- Category: >>>
- Supplier: Shanghai Donsun Welding Equipment Co. Ltd.
Share on (60840327120):
Product Overview
Description
Product Description
Product Description
Features:
Extra functions
“Hot Start”function for easier arc striking;
“Arc Force”to prevent electrode sticking to the piece;smoother welding and deeper penetration;
Built-in Anti-Sticking device to prevent overload and ease the electrode removal from the workpiece.
Weight
Extremely low weight and versatility.
Protections
Fully protected against over-voltage undervoltage and over-heat.
Generator friendly
Designed to work with diesel generators and to avoid failures due to its voltage spikes.
| Model/Parameters | ARC 300DS |
| power supply voltage(V) | 1Phase 220V, Wide Voltage: 95~295V |
| Fre.(HZ) | 50/60 |
| Rated Input Power (KW) | 6.8 |
| Rated input current(A) | 46 |
| Duty Cycle(40℃ 10Min) | 60% 200A 100% 120A |
| No Load Voltage(V) | 63 |
| Welding Current Range(A) | 10~300 |
| Efficiency | ≥80% |
| Net Weight(Kg) | 4.5 |
| Dimensions(mm) | 290x135x220 |
| Electrode Diamerter(mm) | Φ1.6~Φ5.0 |
| Electrode Type | 6013,7018 etc. |
| power factor | 0.70 |
| Insulation Class | H |
| Protection Class | IP23 |
| Cooling | AF |
