Bi Fold Vented Door Front Network Cabinet for DELL. HP Servers

Bi-Fold Vented Door Front Network Cabinet for DELL. HP Servers


Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491;PART1, DIN41494;PART7,GB/T3047.2-92 and ETSI standard

Feathures

> Exquisite design with precise dimension and craftsmanship;

> Toughened temper glass door front and REAR DOUBLE VENTED DOOR.

> Lockable door and side panels for system security;

> Fully adjustable vertical mounting rails;

> Swiveling wheels and legs can be jointly installed to withstand up to 800kg maximum static load;

> Several lockable wiring holes on top/bottom, size of the large hole at the bottom adjustable;

Standard:

Comply with ANSI/EIA RS-310-D, IEC297-2, DIN41494; PART1, DIN41494; PART7, ETSI standard

Material:

High grade cold rolled steel.

Thickness:

Mounting profile: 2.00mm others: 1.2--1.5mm

Loading Capacity:

Static Loading: 800kgs

Surface finish:

Degrease, acid pickling, rust prevention and Parkerizing, pure water cleaning, static electricity plastic painting.

Degree of Protection:

IP20

Body Color:

RAL7035, RAL9004 etc.

Optional Accessory
= Fixed/cantilever shelf, sliding shelf, for 600mm, 800mm, 900mm, 1000mm depth cabinet
= 19'' keyboard frame (350mm, 550mm, 650mm, 730mm)
= 1U, 2U support board
= Vertical Cable manager
=19'' Power distribution unit(PDU)
= 19'' Blanking plate 1U, 2U, 4U
= Heavy duty castor, Heavy duty castor with braker
= Optional lock for side panels
= Earth kit
And so on...
