Product Overview
Description
Zircon sand for spraying and casting ceramics in foundry industry
Zircon also known as zircon sand. It is a mineral consisting mainly of zirconium, silicon, and oxygen that is crystallized from the magma at the time of the formation of igneous rocks. Zircon sand is the most important zirconium mineral. It is the most widely distributed mineral in zirconium minerals, with the largest reserves and the largest type. It is a mineral composed mainly of zirconium silicate. With rutile, ilmenite, monazite and xenotime as raw materials, beneficiation processes such as water, electricity and magnetic separation are carried out in beach sand. Zircon crystallizes in tetragonal pyramids, usually in small square columnar shape, with good and irregular grains. It is a high quality refractory.
Zirconite is a mineral mainly composed of zirconium, silicon and oxygen crystallized from magma when igneous rocks were formed.
| Three. Technical parameters of zircon sand: | |||||||
| Chemical composition | Part of the standard zirconium sand accurate specification(YB834-87) | ||||||
| Senior sand | selected quality | Level 1 | Level 2 | Level 3 | Level 4 | Level 5 | |
| (Zr.Hr)O2 | ≥66.00 | ≥65.00 | ≥65.00 | ≥65.00 | ≥63.00 | ≥60.00 | ≥55.00 |
| TiO2 | ≤0.08 | ≤0.15 | ≤0.50 | ≤1.00 | ≤2.50 | ≤3.50 | ≤8.00 |
| Fe2O3 | ≤0.06 | ≤0.10 | ≤0.25 | ≤0.30 | ≤0.50 | ≤0.80 | ≤1.50 |
| P2O3 | ≤0.20 | ≤0.25 | ≤0.35 | ≤0.50 | ≤0.80 | ≤1.50 | |
| Al2O3 | ≤0.80 | ≤0.80 | ≤0.80 | ≤1.00 | ≤1.20 | ≤1.50 | |
| SiO2 | ≤32.00 | ≤32.00 | ≤34.00 | ≤34.00 | ≤33.00 | ≤32.00 | ≤31.00 |
| size | 80-120mesh,D50,8.35um(325/mesh) | ||||||
| packbag | 25kg/bag ,Moisture-proof woven bag | ||||||
1. The mold coating and the ceramic core used in the mold casting industry.
2. Use in many chemical industries, including cosmetics, cement, food etc.
3. Used for glazing, widely used in a variety of architectural ceramics, sanitary ceramics, daily-use ceramics, a ceramic crafts,etc.
4. Applied in the production of emulsion glass, the television industry and in the color picture tube and glass industry.
5. The main raw material for the preparation of zirconium ZrO2, hafnium and a variety of zirconium products.
6. Also used in glass furnace zircon brick, ladle zircon brick, ramming material, coating and casting material.
7. Zircon sand and zircon powder are mixed with other refractory materials for other purposes.
