100% Pure PTFE Tube by Molded, Extruded, Filled Graphite, Fiberglass, Carbon, MOS2, Bronze
- Category: >>>
- Supplier: Shenyang Zhongye Seals Factory
Share on (60841284510):
Product Overview
Description
PTFE + Bronze Molded Tube High Temperature Industrial Engineering Plastic Tubing Teflon Pipes
Product Description
1,PTFE Moulded Tube Features:
(1)Low temperature and high temperature resistance (-190 °C- +250 °C)
(2)Corrosion resistance , weather resistance
(3)High lubricity, no adhesion
(4)Non-toxic,
(5)Non-flammable
(6)Acid and alkali resistance (except molten alkali metals)
(7)Antioxidant.
2,Mould Size:
| Name | OD(MM) | Thickness(mm) | Max length(m) | ID(MM) | Thickness(mm) | Max length(m) |
Extruded Tube | 40 | 3-3.3 | 3-4.2 | 40 | 4-4.5 | 3-4.2 |
| 50 | 2.5,3-3.3 | 50(49) | ||||
| 59 | 9.5 | 55 | ||||
| 60 | 3-3.3 | 60(59) | ||||
| 65 | 65 | |||||
| 68 | 70 | |||||
| 70 | 3-3.3,4.5 | 80 | ||||
| 74 | 10 | 90 | ||||
| 80 | 4-4.5 | |||||
| 90 | ||||||
| 100 | ||||||
| 115 | ||||||
| 125 | ||||||
| 200 | 5.5 | |||||
Moulded Tube | 15 | 30,35 | 100 | 130 | 150 | 150 |
| 20 | 40,45 | 140 | 150,170 | |||
| 25 | 45 | 150 | 150 | 170 | ||
| 30 | 45,70 | 160 | 180 | |||
| 35 | 50,55,60,65 | 165 | 180 | |||
| 40 | 55,60,65 | 170 | 190,200 | |||
| 45 | 60,65,70 | 180 | 200,220 | |||
| 50 | 60,65,70,80 | 195 | 210 | |||
| 55 | 65,70,80,85 | 200 | 220,230 | |||
| 60 | 70,75,85,95 | 210 | 230,250 | |||
| 65 | 80,85 | 230 | 250 | |||
| 70 | 90 | 240 | 260 | 100 | ||
| 75 | 90,95 | 255 | 280 | |||
| 80 | 100,110 | 260 | 290 | |||
| 85 | 100,105,110,115 | 270 | 290,310 | |||
| 90 | 110,115,120,130 | 285 | 320,330 | |||
| 95 | 110 | 320 | 350 | |||
| 100 | 115 | 335 | 370 | |||
| 105 | 120,130 | 350 | 380 | |||
| 110 | 130,140 | 360 | 390 | |||
| 115 | 130,150 | 370 | 400 | |||
| 120 | 135,145 | 490 | 525 | |||
| 125 | 150 | 530 | 570 |
