Безрамный ЖК монитор видеостена внутренний сенсорный экран с видео стеной

Share on (60845460012):


Price:

Quantity:


Product Overview

Description


 Frameless Lcd Monitor Video Wall Indoor Touch Screen With Video Wall

Product Description



Description

 Excellent super narrow bezel design with just 5.3 mm bezel width between screens

♦ Built-in 3D noise reduction, making the image clean and outline more vivid

♦ HD display 1920x1080

♦ LED backlit technology brings you perfect visual effect

♦ 4K input supported (Option)

♦ Available in a wide range of sizes: 46”, 49", 55” , each display has built-in speakers and comes with a remote control.



Advantages of LCD Video Wall

♦ Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.

♦ High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as stable and clear image.

♦ Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.

♦ Low power consumption and low heat radiation

♦ Long service life lowers the cost of usage and maintenance

♦ Innovative and advanced: 42” to 60” Ultra thin bezel LCD video wall,  the thinnest bezel up to 1.8mm

♦ Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.

♦ Economical and practical: High performance and high quality make it cost less.



The Features of LCD Video Wall

lcd video wall narrow bezel3.5mm.jpg

lcd video wall ips and resolution

Display Types of LCD Video Wall

lcd video wall (3)



Specifications of TYALUX LCD Video Wall TYL-SDID5509-F

LCD Video Wall

Model No.

TYL-SDID5509-F

Panel Size

55" LCD Screen

Backlight Type

LED

Display Area

1209.6(H)x680.4(v)mm

Aspect Ratio

16:9

Max Resolution

1920X1080

Color

8Bit,16.7M

Brightness (nits)

500cd/m2

Contrast

3500:1

Visual Angle (H/V)

178/178 °

Response Time

8 ms

Life Span

>60,000 hours

Bezel width (between screens)

5.5mm

Product Dimension

1215.3(L)*686.1(H)*135.0(D)

Product Weight

35KG

Interfaces (option 1- without 4K input)

Model No.

TYL-DP5509

Input

1*DVI

1*Support HDMI Input

1*VGA  (SVGA / XGA / WXGA)

1*BNC (PAL/NTSC)

1*RS232(RJ45)

Output

1*RS232(RJ45)

2*BNC (PAL/NTSC)

Interfaces (option 2- With 4K input)

Model No.

TYL-DP5515-H4

Input

1*DVI

1*Support HDMI Input

1* DP (Display port)

1*VGA  (SVGA / XGA / WXGA)

1*RS232(RJ45)

Output

1* DP (Display port)

1*RS232(RJ45)

Power

Power Supply

AC100V~240V   50/60Hz

Maximum Power Consumption

170W

Standby Power Consumption

<3W

Working Environment

Working Temperature

0℃~60℃

Working Humidity

5%-95%RH



LCD Video Wall System

systenm diagram for embedded controller application.jpg

system diagram for external controller application.jpg



Installation Types of LCD Video Wall

lcd video wall installion xin.jpg



Feedback

feedback

Product Uses

 Application of  LCD Video Wall



♦ Financial Industry

LCD video wall could be used in the information display terminal of financial industry,  such as stock and security market. These places are usually very spacial and there is crowded population. The wide viewing angle of LCD video wall makes people see the displaying information clearly and effortlessly from different directions and positions.

♦ Commercial Industry

LCD video wall could be used in the display terminal of commercial industry, such as advertising, media, product presentations etc. The LCD video wall could meet the high requirement for bright images and vivid videos because of its high definition and high brightness. At the same time, the LCD video wall  could  work around the clock for years without break, which makes it the best choice for commercial industry to display information with intermission.



♦ Education and Conference System

The LCD video wall could display the information prepared by the educator or conference organizer in advance, which could help the listeners understand the information better, and at the same time, which could save the participants’ a lot of time. In a word, the LCD video wall could improve the efficiency greatly of education and conference.

 Applications of LCD Video Wall

4



Company Information
SDiD-(10)
Packaging & Shipping

lcd video wall packpage.jpg

FAQ

1. Q: Are you a manufacturer or trading company?
    A: We are a professional manufacturer specialized in producing LCD displays since 2003.



2. Q:How long is the warranty?
    A:Our officially promised warranty time is 12 months from the date of delivery.



3. Q:I would like to ask you if it's possible to have my logo on the product.
    A: TYALUX (our brand), neutral appearancecustomized logo, all are available if you like.



4. Q:Which panel you use ?
    A:Samsung and LG A+ panel.



5. Q:I haven't done business with you guys before, how can I trust your company?
    A: Advertising displays received CE, RoHS, ISO9001, CCC etc; Our company is golden supplier more than 10 years; what’s more, our company became a listed company in NEEQ in 2016.
